CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 21 January 2008
150
Mounting Hole MH1: Mounting hole to mount module in user application.
LVD2 Disc SW: Disconnect switch for external contactor 2, when wired as described in
installation section.
Manual LVD Cont Connect: Switches for forced reconnect function.
LVD1 Disc SW: Disconnect switch for external contactor 1, when wired as described in
installation section.
LED: This is a tri-colored LED and will illuminate accordingly for the conditions shown
below.
LEDs:
*
= On
Green
Amber
Red
Condition
*
Normal
*
Minor Alarm
*
Major Alarm
Flashing
External Contactor(s) Manually Opened with
either LVD1 or LVD2 DISC SW
Flashing
Communication Loss with System Controller
Flash (5 sec)
*
Manual Reconnect Command Accepting
Mounting Hole MH2: Mounting hole to mount module in user application.
The ES772A is referenced to VBus(-), therefore, all alarm inputs are either alarmed on an
open or a closure to VBus(-) as described in the following.
