CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 21 January 2008
34
• While installing batteries, follow all safety precautions outlined in the appropriate
battery product manuals.
• The terminal block for the GMT fuse panel is rated for 20A with factory wiring, but
only 10A for field installation.
• All ac inputs for the J85470S1 L12 and L13 must be connected to maximum 60A panel
board breakers from maximum two ac conduit connections.
• CPS6000 outputs are not connected to earth. Earthing of rectifier outputs may be
performed externally to the shelf at a “ground window” or “mesh ground”. Connection
of Ringer tip outputs to CPS6000 Battery or Ground is optional via Ringer Chassis
jumper or external connection.
• The QS841 has an IEEE 802.3 compliant 10Base-T network interface with a
grounded connector shield.. Where intra building lightning surge protection is of
concern, Lineage Power recommends the use of a shielded cable, where both ends are
tied to ground. This cable must be supplied by the user. (example: CAT 5 E STP)
