CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 21 January 2008
31
Thermal Compensation
Thermal Compensation: For thermal compensation, the QS873A Voltage/Thermal probe
(VT-Probe) and its associated cables must be ordered. Refer to Section 5 for details on their
interconnection, and Section 9 for more information on VT-Probes. The probe is provided
with a weatherproof case.
Thermal Compensation/Voltage Monitoring: When voltage monitoring for battery string
voltage imbalance detection is to be implemented in addition to thermal compensation, the
VT-probe and its associated cables must be ordered. Refer to Section 5 for details on their
interconnection, and Section 9 for more information on VT-Probes and voltage monitoring.
Remote Distribution Monitor Module
The Remote Distribution Monitor Module allows the CPS6000 system controller to monitor
for open circuit breakers and fuses, monitor current through a battery shunt, and
monitor/control low-voltage disconnect contactors at an external distribution panel that is
bulk-fed from the CPS6000 system. See Section 11 for more details.
Inter-Shelf Kit for Multiple Shelves
Supplementary bulk-output shelves may be added to a bulk-output primary shelf to create a
larger plant. Only the primary shelf requires a controller. The inter-shelf kit contains a QS845
shelf controller (with blank faceplate) and a connecting cable with connectors on both ends.
Refer to Appendix F for thermal considerations while paralleling shelves.
Lugs
Please refer to ordering guide H569-470 for lugs specific to distribution modules. The
following table is generic and needs to be used in conjunction with the ordering guide.
Note: TEPS lugs in the WP91412 specification are Burndy parts. The Panduit and T&B (and
any others) may have different dimensions.
GA Description
WP-91412
List Comcode Burndy Equivalent Panduit Similar T&B Similar
2 Straight, STR 54 405348202 YA2CL-2TC14 LCD2-14A-Q 54207 (STR)
2 Straight, FLEX 8 405347683 YAV2C-L2TC14-FX LCDX2-14A-E 54208 (Flex)
2 45°, STR ? ? YA2CL-2TC14-45 LCD2-14AH-Q 54207UF (STR)
2 45°, FLEX 193 408210524 YAV2C-L2TC14-FX-45 LCDX2-14AH-E 54208UF (Flex)
4 Straight, STR / FLEX 5 405347576 YAV4C-L2TC14-FX LCDX4-14A-L (FLEX)
LCD4-14A-L (STR) 54206 (STR)
54206 (FLEX)
4 45°, STR / FLEX ? ? YAV4C-L2TC14-FX-45 LCDX4-14AH-L (FLEX)
LCD4-14AH-L (STR) 54206UF (STR)
54206UF (FLEX)
6 Straight, STR / FLEX 3 405347519 YAV6C-L2TC14-FX LCDX6-14A-L (FLEX)
LCD6-14A-L (STR) 54205 (STR)
54205 (FLEX)
6 45°, STR / FLEX ? ? YAV6C-L2TC14-FX-45 LCDX6-14AH-L (FLEX)
LCD6-14AH-L (STR) 54205UF (STR)
54205UF (FLEX)
8 Straight, STR / FLEX 75 406021626 YA8CL2TC14 LCDX8-14A-L (FLEX)
LCD8-14A-L (STR) 542040410 (STR)
542040410 (FLEX)
8 45°, STR / FLEX ? ? YA8CL2TC14-45 LCDX8-14AH-L (FLEX)
LCD8-14AH-L (STR) N/A
