One Ringer per Ringer Chassis is non-redundant (simplex).
Two Ringers per Ringer Chassis is 1 + 1 redundant (duplex).
Ringer
Comcode
QS820A Ringer
108990082
AC Power Cables
An ac power cable must be ordered. A standard ac cable set will not fit in the CPS6000 shelf.
Verify that the sum of the input currents for all the rectifiers served by an ac circuit breaker
does not exceed 80% of the breaker’s rating.
Table 3-A: Rectifier AC Input Current Table
Lineage
Power
Rectifier (A)
Model
Number of
Rectifier
Nominal
Input
Voltage
Number of
Rectifiers
per AC feed
Nominal AC
Current (A)
Minimum Circuit
Breaker value
recommended
(A)*
75°C Minimum
Recommended
Wire Gauge
(AWG)*
120 1 7.8
15
14
120 2 15.6 20
12
120 3 23.4 30
10
120 4 31.2 40
8
120 5 39.1 50
8
208
1
4.4
15
14
208
2
8.8
15
14
208
3
13.2
20
12
208
4
17.6
25
10
15A QS861A
208
5
22.0
30
10
208 1 6
15
14
208 2 12
15
14
208 3 18
25
10
208 4 24
30
10
20A QS852A
208 5 30
40
8
208 1 7.4
15
14
208 2 14.8 20
12
208 3 22.2 30
10
208 4 29.6 40
8
25A QS853A
208 5 37.0 50
8
120 1 13.0 20
12
120 2 26.0 35
8
120 3 39.1 50
8
208
1
8.8
15
14
208
2
17.6
25
10
208
3
26.4
35
8
25/30A QS862A
208
4
35.3
45
8
208 1 11.8 15
14
208 2 23.5 30
10
40A QS864A
208 3 35.3 45
8
208
1
14.5
20
12
50A QS865A
208
2
29.1
40
8
*Conduit and further temperature deratings may be required in some installations .Cross-check table with
local code and regulation requirements
