CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 21 January 2008
39
5 Installation
CPS6000 Installation
Purpose
CPS6000 Shelf Installation guide for generic installations. Additional requirements are
needed for application specific installations. Refer to Appendix F for spacing requirements.
Audience
Field application personnel.
Precautions
Observe ESD protection while installing circuit packs
Safety
• Always consider personal safety.
• Make sure the system is properly grounded per the National Electrical Code and local
building codes.
• Remove all metal jewelry before beginning the installation.
Installation Tools
•Wire cutters and strippers •Digital meter, +/- 0.02%
•Heat shrink gun •Screw Drivers (flat-blade and Phillips)
•Torque wrench (0-240 in-lb / 28 Nm) •ESD wrist strap
•48 Volt test load
Parts List
Comcode Qty Description
Single-Wide
Distribution Module 801085119
802286773
802841635
407646330
408515823
7-22050-2
2
2
2
2
1
2 3/8-inch bolt
3/8-inch lock washer
3/8-inch flat washer
Shelf plastic bushing
Fuse puller
#4 screw
Double-Wide
Distribution Module 801085119
802286773
802841635
407646330
7-22050-2
848702007
2
2
2
2
4
1 3/8-inch bolt
3/8-inch lock washer
3/8-inch flat washer
Shelf plastic bushing
#4 screw
Spacer
Ringer Chassis 7-22050-2 1 #4 Screw
Shelf 901078717 8 12-24 mounting screw
