CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 21 January 2008
18
Table 2-B: CPS6000 Physical Specifications
Height
in. (mm)
Width
in. (mm)
Depth
in. (mm)
Weight
lb (kg)
Rectifier 3.41 (86.6) 3.4 (86.3) 11.2 (284.5) 5.75 (2.6)
Ringer Chassis 3.41 (86.6) 3.4 (86.3) 11.2 (284.5) 3.45 (1.6)
Ringer 2.4 (61.0) 1.51 (38.4) 9.9 (252) 1.25 (0.6)
19-Inch Shelf 3.41 (86.6) 17.37 (441.2) 12 (304) –
front access
13.25 (337)-
rear access
7.5 (3.41)
23-Inch Shelf 3.41 (86.6) 20.95 (532.1) 12 (304) –
front access
13.25 (337)-
rear access
12.7 (5.77)
Single-Slot Distribution Module 3.41 (86.6) 5.1 (129.5) 12 (304) 9 (4.1)
Double-Slot Distribution Module 3.41 (86.6) 8.5 (216) 12 (304) TBM
Bulk Output Module 3.41 (86.6) 1.59 (40.4) 12 (304) 4 (1.8)
23-Inch Frame Mounting
Requirements Standard 23 and 26-inch relay racks:
•Vertical mounting centers: 1.0 in. (25 mm) and 1.75 in.
(44 mm)
•Horizontal mounting centers: 22.32 in. (567 mm)
19-Inch Frame Mounting
Requirements Standard 19-inch relay racks:
•Vertical mounting centers: 1.0 in. (25 mm) and 1.75 in.
(44 mm)
•Horizontal mounting centers: 18.31 in. (465 mm)
Table 2-C: CPS6000 Shelf Specifications
Control Unit QS840A / QS841A
Nominal Output Voltages 48/52/54.5 Vdc
Operating Voltage Range 42 to 58 Vdc
Maximum Output Current 200A per 19-inch shelf; 250A per 23-inch shelf
(see Note 1)
Nominal Input Voltage 100/120/200/208/240 Vac
Input Voltage Ranges 85 to 275 Vac
Max Nominal Input Current per Rectifier (based
on 25A rectifier for low line ac, and 50A
rectifier for high line ac) 13A at 120 Vac
14.5A at 208 Vac
Boost Voltage 48 to 58 Vdc
Output Voltage Regulation ±0.5%
Output Noise:
Ripple
Wideband
Noise
100 mVrms maximum, 10 Hz to 20 MHz
< 250 mV pk-pk over the range dc to 100 MHz
Load Share Accuracy 1.5A (maximum) for QS862A
Maximum Discharge Current
(see Note) 227A per 19-inch shelf; 284A per 23-inch shelf
Maximum Recharge Current Installed rectifier capacity minus plant load
Low-Voltage Disconnect 39 to 50 Vdc
Low-Voltage Reconnect 39 to 55 Vdc
Heat Dissipation 177W (604 BTU) per QS862A at full load and
120 Vac operation;
