CPS6000 –48V Indoor/Outdoor Power Shelf

Issue 21 January 2008

132W (450 BTU) per QS861A rectifier at full
load and 120 Vac operation;
212W (724 BTU) per QS862A at full load and
240 Vac operation;
130W (445 BTU) per QS861A rectifier at full
load and 240 Vac operation;
267W (911 BTU) per QS865A rectifier at full
load and 240 Vac operation;

Power Factor

> 0.98 for loads > 50% of full load

Note: Maximum current is based on Bulk Output Module and 50A QS865A rectifier. System capacity
will decrease with lower rated rectifiers.

Power Slots Available for Rectifiers or Ringer Chassis

Distribution Module

Shelf

None (Bulk Output Module)

Single-Wide Double-Wide

19-Inch Shelf

23-Inch Shelf

Rectifiers

Table 2-D: QS861A Rectifier Specifications

Nominal Output Voltage

48/52/54.5 Vdc

Operating Output Voltage Ranges

42 to 58 Vdc

Boost Voltage

48 to 58 Vdc

Output Current

0 to 15A at 54.5V

Nominal Input Voltage

100/120/200/208/240 Vac (Shutdown from 135 to
150V)

Input Voltage Ranges

85 to 275 Vac

Input Current

8A at 120 Vac
4.4A at 208 Vac

Operating Frequency Range

45 to 66 Hz

Operating Temperature

-40 to +75 °C

Output Voltage Regulation

±0.5%

Output Noise, Ripple

250 millivolts peak to peak maximum, over the
range dc to 100 MHz

Load Share Accuracy

1.5A maximum deviation between rectifiers

Heat Dissipation (per rectifier, full load)

132W (450 BTU) at 120 Vac operation
130W (445 BTU) at 240 Vac operation

Power Factor

>0.99 (low-line), >0.98 (high line)

Selective High-Voltage Shutdown

Above 58 Vdc

Backup High-Voltage Shutdown

Above 60 Vdc for 1 millisecond

Table 2-E: QS852A Rectifier Specifications
