Page 141
CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 21 January 2008
141
10 Ringer Chassis and Ringers
Ringer Chassis
Overview
Ringer Chassis provide
•
One ringing output – 100VA maximum
•
Support for one (non-redundant) or two Ringers (1 + 1 redundant)
•
Fans – Ringer powered, controlled, and monitored
•
Ringing output connector
•
Ringing type selection (Tip) Jumper J12
Redundant Configuration
1 + 1 redundant (duplex) operation
•
Two ringers are installed in a Ringer Chassis
•
Ringing output from that Ringer Chassis is powered by the primary ringer (the one on
the right)
•
Should the primary ringer be removed or fail
•
Ringing output will be provided by the spare ringer (the one on the left)
•
An alarm will be sent and displayed by the Controller.
Non-Redundant Configuration
Non-redundant (simplex) operation
•
One ringer is installed in a Ringer Chassis
•
Ringing output from that Ringer Chassis is powered by that ringer
•
Should that ringer be removed or fail, ringing output will not provide ringing, and an
alarm will be sent and displayed by the Controller.
