GE Industrial Solutions CPS6000 User Manual
Page 7
CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 21 January 2008
7
CPS6000 systems may include up to 4 bulk-output shelves: an Initial shelf with controller,
and up to three supplemental shelves. External distribution is used with multi-shelf systems.
Ringer Chassis may be installed in Power Slots. Each Ringer Chassis supports one ringing
output in either non-redundant (simplex) or 1 + 1 redundant (duplex) operation. Ringer
distribution is direct from the Ringer Chassis.
The system controller card is powered by the system bus voltage and is located on the left
side of the shelf. The controller allows setting of system parameters, and various alarm
thresholds locally on the four-line LCD graphics display with intuitive navigation. The
controller can perform periodic battery tests and has a provision for user-definable alarm
inputs as well as alarm relays.
Applications
CPS6000 fits Outside Plant(OSP) applications, digital loop carrier, remote switch, fiber in the
loop, cable television cabinets, Intelligent Vehicle Highway System (IVHS), Personal
Communications Service (PCS), cellular, and customer premises applications.
