CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 21 January 2008
122
ID1-6 The operation “Type” of each shunt monitoring circuit on system
distribution boards 1-6 must be assigned based upon actual system
implementation. The operational Type may be: None (For no shunt),
Battery (Monitoring battery currents), and Load (for load currents). The
factory default is Battery for ID1 and NONE for the rest.
ID1-6 Rating The current rating of each shunt being monitored by the system
distribution boards 1-6 must be configured based upon actual system
implementation. All shunts are assumed to be 50mV. The current rating
may be from 0-9999 Amps. The factory default is 300A for ID1-4 and
600 for ID5-6.
Rectifiers
The following features pertaining to rectifiers can be configured:
Redundancy An alarm is automatically generated when the rectifier capacity On-line
in the system falls below N+1 based on the present system load. The
factory default for this feature is Disabled.
Rectifier On Threshold The system DC bus threshold that rectifiers placed into Standby will
automatically be turned on. This value can be set between -40 and -
50V. The factory default is -44.0V
Remote Off Provides the ability to disable or enable the capability of placing a
rectifier into Standby operation through remote means such as the
network, modem, or local terminal. The factory default for this feature is
Disabled.
Current Limit Adjustable from 30-100%.
Batteries
This section provides all the configurable items associated with batteries and battery
management.
Battery Type The type of batteries used in the system and can be set for the following
battery types:
• SE48S63 (Li-LMP)
• SE48S80 (Li-LMP)
• NSB110FT (VRLA)
• NSB170FT (VRLA)
• NSB60FT (VRLA)
• IR30EC (VRLA)
• IR40EC (VRLA)
• 12A100FT (VRLA)
• 12A150FT (VRLA)
• 12IR150/150LP (VRLA)
• L48V60FTX (Li-ELiTE)
• 6A95-15L (VRLA)
• 3A95-21L (VRLA)
