CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 21 January 2008
168
DC Plant Related Commands
obj,attr description sta cha ope type range of values
dc1,stt Plant state x x text “FLOAT”, “BOOST”
dc1,vdc Plant voltage x number dd.dd V
dc1,adc External Battery Shunt Size x number ddd.d A
dc1,sha1 Plant shunt size x x number 0-9999: 200, 0: none
dc1,trd Plant total rectifier drain x number ddd.d A
dc1,isd Imminent shutdown enable x x number 0: disable, 1: enable
dc1,cap Total rectifier capacity x number ddd.dA
dc1,rss Rectifier restart x x number 0:no action 1:restart
dc1,bod Battery on discharge x number 0:on discharge, 1: not on
discharge
Plant State: The plant is normally in the float-charge mode; however, the super-user
may instruct the plant to enter the boost-charge mode.
Plant Voltage: The voltage of the plant at the time of querying.
Plant Current: The current being drawn by the load at the time of querying.
External Battery Shunt Size: External battery shunt amp rating.
Plant Total Rectifier Drain: The current being drawn by the battery and load from
the plant at the time of querying.
Imminent Shutdown Enable: Factory shipped disabled. When enabled, prior to
disconnecting of LVD contactor during battery discharge, the controller will transmit
the Imminent Shutdown alarm to the host indicating batteries will disconnect from the
load in 15 seconds. See Imminent Shutdown in Section 6 for more details on this
feature.
Total Rectifier Capacity: Sum of the rated outputs of installed rectifiers.
