CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 21 January 2008
117
Float Voltage Alarms Very High Major, Very High Minor, BD Major and Very Low Major
Boost Voltage Alarms Very High Major, High Minor, and BD Major
High Batt Temp Highest temperature being measured by the thermal probes
Reserve Low Low battery reserve time alarm
High Ambient Temp High ambient temperature alarm
Low Ambient Temp Low ambient temperature
Ringers
The NX400 does not contain ringers. However, the QS841A has the capability of managing
eight ringer chassis in a system. The ringer states and output VA would be available when
ringers are present in the system.
Enable-Disable Info
This section of the menu displays the enable/disable status of some of the QS841A features.
These values are set by factory default but can be individually configured in the field.
Temp Comp Temperature compensation
Low Temp Comp Low temperature compensation
Recharge Ilim Recharge current limit
Emrgncy Pwr Off Emergency Power Off (Remote Emergency Battery Disconnect). Enabled
when contact closure is applied to the EPO inputs.
Alarm Test Form-C Alarm Test Feature
Auto Boost Automatic boost charge
Auto Batt Test Automatic battery test
Rect Redund Rectifier redundancy
Mid-Cell V Mon Mid-cell voltage monitoring
Imminent Shutdn Imminent system shutdown alarm (LVBD)
Disconnects LVBD (Low Voltage Battery Disconnect) and LVLD1-3 (Low Voltage
Load Disconnects)
Ringer DC Offset Ability to reference the output of the ringer to a DC offset
Ringer Redund Ringer Redundancy Alarm feature
Remote Rect Off Remote Rectifier Off – Individual Remote Rectifier Standby
Local Write Whether or not the system can be configured through the local port.
Modem Write Whether or not the system can be configured through the modem port.
Network Write Whether or not the system can be configured through the network.
Usernames Whether or not usernames and password identification has been enabled
