9 qs872a distribution monitoring module, Overview – GE Industrial Solutions CPS6000 User Manual
Page 139
CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 21 January 2008
139
9 QS872A Distribution Monitoring
Module
Overview
This section describes the Distribution Monitoring Module features, functions, and alarms.
Figure 9-1 shows the QS872A Distribution Monitoring Module board. This board is installed
on the left wall of the Distribution Module (if equipped). This board may also be used in
external distribution panels.
Figure 9-1:Distribution Monitoring Module
LED: This is a tri-color LED and will illuminate accordingly for the conditions shown below.
LEDs:
*
= On
Green
Amber
Red
Condition
*
Normal
*
Minor Alarm
*
Major Alarm
Flashing
Communication Loss with System Controller
