TM

E8950

INSTALLATION GUIDE

ZL0105-0B

PAGE 77

©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected]

02131

Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.

Data Variable

Description

BACnet

Object

Units

COV_

Increment

Modbus

Address

Comments

Voltage 1 Alarm Status

Write 0 to alarm bits to

clear alarms

AV160

n/a

1

241

Not used on E3xCxxx models; reports QNAN
Latching Alarms are cleared by writing a 0 to its alarm bit. Writing to

Non-Latching alarm is ignored.

Bit 0: High Latching Alarm
Bit 1: Low Latching Alarm
Bit 2-7: Reserved for future use (reads 0)
Bit 8: High Non-Latching Alarm
Bit 9: Low Non-Latching Alarm
Bit 10-15: Reserved for future use (reads 0)

Voltage 2 Alarm Status

Write 0 to alarm bits to

clear alarms

AV161

n/a

1

242

Not used on E3xCxxx models; reports QNAN
Latching Alarms are cleared by writing a 0 to its alarm bit. Writing to

Non-Latching alarm is ignored.

Bit 0: High Latching Alarm
Bit 1: Low Latching Alarm
Bit 2-7: Reserved for future use (reads 0)
Bit 8: High Non-Latching Alarm
Bit 9: Low Non-Latching Alarm
Bit 10-15: Reserved for future use (reads 0)

Voltage 3 Alarm Status

Write 0 to alarm bits to

clear alarms

AV162

n/a

1

243

Not used on E3xCxxx models; reports QNAN
Latching Alarms are cleared by writing a 0 to its alarm bit. Writing to

Non-Latching alarm is ignored.

Bit 0: High Latching Alarm
Bit 1: Low Latching Alarm
Bit 2-7: Reserved for future use (reads 0)
Bit 8: High Non-Latching Alarm
Bit 9: Low Non-Latching Alarm
Bit 10-15: Reserved for future use (reads 0)

Power Up Counter

Power Up Counter

AV163

n/a

1

531

Number of power-up cycles (write 0 to reset)

User Defined Status

Register

1 in bit 0 enables CT

phase assignment

AV164

n/a

1

62017

User Defined Status Register:
Bit 0: Enable User CT Phase Assignment
Bit 1-15: Reserved

Voltage Phase for Aux

Channel 1

0=phase-1/A, 1=phase-

2/B, 2=phase-3/C

AV165

n/a

1

62158

Not used on E3xCxxx models; reports QNAN

Voltage Phase for Aux

Channel 2

0=phase-1/A, 1=phase-

2/B, 2=phase-3/C

AV166

n/a

1

62159

Not used on E3xCxxx models; reports QNAN

Voltage Phase for Aux

Channel 3

0=phase-1/A, 1=phase-

2/B, 2=phase-3/C

AV167

n/a

1

62160

Not used on E3xCxxx models; reports QNAN

Analog_Output objects
AUX Resets: Write value

to reset

10203=kWh,

29877=Max Current &

Max kW

AO1

n/a

1

294

Write the listed value to perform the corresponding reset:
10203 = Clear kWh value to zero
29877 = Clear Max Current and Max kW values to zero

Global Resets: Write

value to reset

10203=kWh, others…

AO2

n/a

1

295

Write the listed value to perform the corresponding reset:
26012 = Begin new Demand Sub-interval
26013 = Reset Demand
31010 = Reset all Latching Alarms
10203 = Clear all kWh values to zero
29877 = Clear all Max Current and Max kW values to zero
20097 = Clear all Max Demand values to zero

Channel 1 Reset

10203=kWh,

29877=Max Current &

Max kW

AO3

n/a

1

1126

Write the listed value to perform the corresponding reset:
10203 = Clear kWh value to zero
29877 = Clear Max Current and Max kW values to zero

Channel 2 Reset

10203=kWh,

29877=Max Current &

Max kW

AO4

n/a

1

1127

E30Bxxx/Cxxx and E31Bxxx/Cxxx Branch Circuit Meters cont.
