Data Variable
Description
BACnet
Object
Units
COV_
Increment
Modbus
Address
Comments
Error Bitmap3
(placeholder - bits TBD)
Error Bitmap3
(placeholder - bits TBD)
AI64
n/a
1
232
Error Bitmap4
(placeholder - bits TBD)
Error Bitmap4
(placeholder - bits TBD)
AI65
n/a
1
233
Error Bitmap5
(placeholder - bits TBD)
Error Bitmap5
(placeholder - bits TBD)
AI66
n/a
1
234
Error Bitmap6
(placeholder - bits TBD)
Error Bitmap6
(placeholder - bits TBD)
AI67
n/a
1
235
Amps: Channel 1
Instantaneous Current -
Channel 1
AI68
Amps
5
2252/2253
Amps: Channel 2
Instantaneous Current -
Channel 2
AI69
Amps
5
2254/2255
Amps: Channel 3
Instantaneous Current -
Channel 3
AI70
Amps
5
2256/2257
Amps: Channel 4
Instantaneous Current -
Channel 4
AI71
Amps
5
2258/2259
Amps: Channel 5
Instantaneous Current -
Channel 5
AI72
Amps
5
2260/2261
Amps: Channel 6
Instantaneous Current -
Channel 6
AI73
Amps
5
2262/2263
Amps: Channel 7
Instantaneous Current -
Channel 7
AI74
Amps
5
2264/2265
Amps: Channel 8
Instantaneous Current -
Channel 8
AI75
Amps
5
2266/2267
Amps: Channel 9
Instantaneous Current -
Channel 9
AI76
Amps
5
2268/2269
Amps: Channel 10
Instantaneous Current -
Channel 10
AI77
Amps
5
2270/2271
Amps: Channel 11
Instantaneous Current -
Channel 11
AI78
Amps
5
2272/2273
Amps: Channel 12
Instantaneous Current -
Channel 12
AI79
Amps
5
2274/2275
Amps: Channel 13
Instantaneous Current -
Channel 13
AI80
Amps
5
2276/2277
Amps: Channel 14
Instantaneous Current -
Channel 14
AI81
Amps
5
2278/2279
Amps: Channel 15
Instantaneous Current -
Channel 15
AI82
Amps
5
2280/2281
Amps: Channel 16
Instantaneous Current -
Channel 16
AI83
Amps
5
2282/2283
Amps: Channel 17
Instantaneous Current -
Channel 17
AI84
Amps
5
2284/2285
Amps: Channel 18
Instantaneous Current -
Channel 18
AI85
Amps
5
2286/2287
Amps: Channel 19
Instantaneous Current -
Channel 19
AI86
Amps
5
2288/2289
Amps: Channel 20
Instantaneous Current -
Channel 20
AI87
Amps
5
2290/2291
Amps: Channel 21
Instantaneous Current -
Channel 21
AI88
Amps
5
2292/2293
Amps: Channel 22
Instantaneous Current -
Channel 22
AI89
Amps
5
2294/2295
E30Bxxx/Cxxx and E31Bxxx/Cxxx Branch Circuit Meters cont.
