E8950 INSTALLATION GUIDE
ZL0105-0B PAGE 24 ©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected] 02131
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
H8238 Series Multi-Circuit Meters (H8238, H8238E & H8238EL)
Each H8238 contains up to 8 logical meters, each with 73 data objects, for a total of 584 data objects for one H8238 if all 8 meters are enabled. The H8238 operates at 9600 or
19200 baud.
Data Variable Description BACnet
Object
Units COV_
Increment
Modbus
Address
Comments
Analog_input objects: (Read-only)
kWh Energy: Total
Accumulated Real Energy AI1 kWh 0 259/260
kW: Total Total Instantaneous Real Power AI2 kW 1 261/262
kVAR: Total Total Instantaneous Reactive
Power
AI3 kVAR 1 263/264
KVA: Total Total Instantaneous Apparent
Power
AI4 kVA 1 265/266
PF: Total Total Instantaneous Power
Factor
AI5 PF 0.01 267/268
Volts: L-L Avg Voltage L-L average of active
phases
AI6 Volts 5 269/270
Volts: L-N Avg Voltage L-N average of active
phases
AI7 Volts 5 271/272
Amps: Avg Current Avg of active phases AI8 Amps 5 273/274
Frequency Instantaneous Frequency AI9 Hz 0.01 275/276 Frequency: measured from the phase A voltage input.
Range is 40 to 70 Hz. If voltage is insufficient for an
accurate frequency determination, this register reads as
0xFFFF for integer and 0x7FC00000 for float.
kW: Ph A Instantaneous Real Power
Phase A
AI10 kW 1 277/278
kW: Ph B Instantaneous Real Power
Phase B
AI11 kW 1 279/280
kW: Ph C Instantaneous Real Power
Phase C
AI12 kW 1 281/282
PF: Ph A Instantaneous Power Factor
Phase A
AI13 PF 0.01 283/284
PF: Ph B Instantaneous Power Factor
Phase B
AI14 PF 0.01 285/286
PF: Ph C Instantaneous Power Factor
Phase C
AI15 PF 0.01 287/288
Volts: Ph A-B Instantaneous Voltage Phase A
to Phase B
AI16 Volts 5 289/290
Volts: Ph B-C Instantaneous Voltage Phase B
to Phase C
AI17 Volts 5 291/292
Volts: Ph A-C Instantaneous Voltage Phase A
to Phase C
AI18 Volts 5 293/294
Volts: Ph A-N Instantaneous Voltage Phase A
to Neutral
AI19 Volts 5 295/296
Volts: Ph B-N Instantaneous Voltage Phase B
to Neutral
AI20 Volts 5 297/298
Volts: Ph C-N Instantaneous Voltage Phase C
to Neutral
AI21 Volts 5 299/300
Amps: Ph A Instantaneous Current Phase A AI22 Amps 5 301/302
Amps: Ph B Instantaneous Current Phase B AI23 Amps 5 303/304
Amps: Ph C Instantaneous Current Phase C AI24 Amps 5 305/306
Amps: Neutral Instantaneous Neutral Current AI25 Amps 0.1 307/308 Only Active in 6-Meter mode (reads 65535 in 8-meter
mode)
kW: Average Average Real Power since last
reset
AI26 kW 1 309/310
