E8950 INSTALLATION GUIDE
ZL0105-0B PAGE 56 ©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected] 02131
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Data Variable Description BACnet
Object
Units COV_
Increment
Modbus
Address
Comments
Branch 28 Alarm Status Write 0 to alarm bits to
clear alarms
AV136 n/a 1 205
Branch 29 Alarm Status Write 0 to alarm bits to
clear alarms
AV137 n/a 1 206
Branch 30 Alarm Status Write 0 to alarm bits to
clear alarms
AV138 n/a 1 207
Branch 31 Alarm Status Write 0 to alarm bits to
clear alarms
AV139 n/a 1 208
Branch 32 Alarm Status Write 0 to alarm bits to
clear alarms
AV140 n/a 1 209
Branch 33 Alarm Status Write 0 to alarm bits to
clear alarms
AV141 n/a 1 210
Branch 34 Alarm Status Write 0 to alarm bits to
clear alarms
AV142 n/a 1 211
Branch 35 Alarm Status Write 0 to alarm bits to
clear alarms
AV143 n/a 1 212
Branch 36 Alarm Status Write 0 to alarm bits to
clear alarms
AV144 n/a 1 213
Branch 37 Alarm Status Write 0 to alarm bits to
clear alarms
AV145 n/a 1 214
Branch 38 Alarm Status Write 0 to alarm bits to
clear alarms
AV146 n/a 1 215
Branch 39 Alarm Status Write 0 to alarm bits to
clear alarms
AV147 n/a 1 216
Branch 40 Alarm Status Write 0 to alarm bits to
clear alarms
AV148 n/a 1 217
Branch 41 Alarm Status Write 0 to alarm bits to
clear alarms
AV149 n/a 1 218
Branch 42 Alarm Status Write 0 to alarm bits to
clear alarms
AV150 n/a 1 219
AUX Channel (phase 1)
Alarm Status
Write 0 to alarm bits to
clear alarms
AV151 n/a 1 220
AUX Channel (phase 2)
Alarm Status
Write 0 to alarm bits to
clear alarms
AV152 n/a 1 221
AUX Channel (phase 3)
Alarm Status
Write 0 to alarm bits to
clear alarms
AV153 n/a 1 222
AUX Channel (Neutral)
Alarm Status
Write 0 to alarm bits to
clear alarms
AV154 n/a 1 223
Overvoltage Alarm Timer Alarm event duration
threshold
AV155 Seconds 1 236 Controls entry into Overvoltage alarm state. A return to a non-alarm
state is instantaneous. All channels use these same global timers. Note
that the parameter measurement update rate is 1.6 sec, which limits
the effective resolution of these timers.
Undervoltage Alarm
Timer
Alarm event duration
threshold
AV156 Seconds 1 237 Controls entry into Undervoltage alarm state. A return to a non-alarm
state is instantaneous. All channels use these same global timers. Note
that the parameter measurement update rate is 1.6 sec, which limits
the effective resolution of these timers.
Overvoltage Alarm
Threshold
Overvoltage level
threshold (0=OFF)
AV157 Volts 5 238
Undervoltage Alarm
Threshold
Undervoltage level
threshold (0=OFF)
AV158 Volts 5 239
Voltage Alarm Hysteresis Voltage Alarm Hysteresis
(% of setpoint)
AV159 Percent 1 240 Percentage of setpoint
E30A042 and E30A142x Branch Circuit Power Meter, cont.
