Veris Industries E8950 Install - Manual (Page 52)

TM
E8950 INSTALLATION GUIDE
ZL0105-0B PAGE 52 ©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected] 02131
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Data Variable Description BACnet
Object
Units COV_
Increment
Modbus
Address
Comments
Branch 1 CT Size Branch 1 CT Size AV4 Amps 5 73
These are writable ONLY on E31Axxx split-core models.
These are NOT WRITABLE on E30Axxx solid-core models because the CT
size is fixed (at 100 A). Other values written revert to 100 A the next
time the meter is scanned.
Branch 2 CT Size Branch 2 CT Size AV5 Amps 5 74
Branch 3 CT Size Branch 3 CT Size AV6 Amps 5 75
Branch 4 CT Size Branch 4 CT Size AV7 Amps 5 76
Branch 5 CT Size Branch 5 CT Size AV8 Amps 5 77
Branch 6 CT Size Branch 6 CT Size AV9 Amps 5 78
Branch 7 CT Size Branch 7 CT Size AV10 Amps 5 79
Branch 8 CT Size Branch 8 CT Size AV11 Amps 5 80
Branch 9 CT Size Branch 9 CT Size AV12 Amps 5 81
Branch 10 CT Size Branch 10 CT Size AV13 Amps 5 82
Branch 11 CT Size Branch 11 CT Size AV14 Amps 5 83
Branch 12 CT Size Branch 12 CT Size AV15 Amps 5 84
Branch 13 CT Size Branch 13 CT Size AV16 Amps 5 85
Branch 14 CT Size Branch 14 CT Size AV17 Amps 5 86
Branch 15 CT Size Branch 15 CT Size AV18 Amps 5 87
Branch 16 CT Size Branch 16 CT Size AV19 Amps 5 88
Branch 17 CT Size Branch 17 CT Size AV20 Amps 5 89
Branch 18 CT Size Branch 18 CT Size AV21 Amps 5 90
Branch 19 CT Size Branch 19 CT Size AV22 Amps 5 91
Branch 20 CT Size Branch 20 CT Size AV23 Amps 5 92
Branch 21 CT Size Branch 21 CT Size AV24 Amps 5 93
Branch 22 CT Size Branch 22 CT Size AV25 Amps 5 94
Branch 23 CT Size Branch 23 CT Size AV26 Amps 5 95
Branch 24 CT Size Branch 24 CT Size AV27 Amps 5 96
Branch 25 CT Size Branch 25 CT Size AV28 Amps 5 97
Branch 26 CT Size Branch 26 CT Size AV29 Amps 5 98
Branch 27 CT Size Branch 27 CT Size AV30 Amps 5 99
Branch 28 CT Size Branch 28 CT Size AV31 Amps 5 100
Branch 29 CT Size Branch 29 CT Size AV32 Amps 5 101
Branch 30 CT Size Branch 30 CT Size AV33 Amps 5 102
Branch 31 CT Size Branch 31 CT Size AV34 Amps 5 103
Branch 32 CT Size Branch 32 CT Size AV35 Amps 5 104
Branch 33 CT Size Branch 33 CT Size AV36 Amps 5 105
Branch 34 CT Size Branch 34 CT Size AV37 Amps 5 106
Branch 35 CT Size Branch 35 CT Size AV38 Amps 5 107
Branch 36 CT Size Branch 36 CT Size AV39 Amps 5 108
Branch 37 CT Size Branch 37 CT Size AV40 Amps 5 109
Branch 38 CT Size Branch 38 CT Size AV41 Amps 5 110
Branch 39 CT Size Branch 39 CT Size AV42 Amps 5 111
Branch 40 CT Size Branch 40 CT Size AV43 Amps 5 112
Branch 41 CT Size Branch 41 CT Size AV44 Amps 5 113
Branch 42 CT Size Branch 42 CT Size AV45 Amps 5 114
E30A042 and E30A142x Branch Circuit Power Meter, cont.
