E8950 INSTALLATION GUIDE
ZL0105-0B PAGE 20 ©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected] 02131
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
H8436 Series Energy Meters (H8436V, H8436VB & H8436VBS)
The H8436 has 34 data objects and operates at 9600 or 19200 baud.
Data Variable Description BACnet
Object
Units COV_
Increment
Modbus
Address
Comments
Analog_input objects: (Read-only)
kWh Energy: Total
Accumulated Real Energy AI1 kWh 0 259/260
kW: Total Total Instantaneous Real Power AI2 kW 1 261/262
kVA: Total Total Instantaneous Apparent Power AI3 kVA 1 263/264
kVAR: Total Total Instantaneous Reactive Power AI4 kVAR 1 265/266
PF: Total Total Instantaneous Power Factor AI5 PF 0.01 267/268
Volts: L-L Avg Voltage L-L average of active phases AI6 Volts 5 269/270
Volts: L-N Avg Voltage L-N average of active phases AI7 Volts 5 271/272
Amps: Avg Current Avg of active phases AI8 Amps 5 273/274
kW: Ph A Instantaneous Real Power Phase A AI9 kW 1 275/276
kW: Ph B Instantaneous Real Power Phase B AI10 kW 1 277/278
kW: Ph C Instantaneous Real Power Phase C AI11 kW 1 279/280
PF: Ph A Instantaneous Power Factor Phase A AI12 PF 0.01 281/282
PF: Ph B Instantaneous Power Factor Phase B AI13 PF 0.01 283/284
PF: Ph C Instantaneous Power Factor Phase C AI14 PF 0.01 285/286
Volts: Ph A-B Instantaneous Voltage Phase A to Phase B AI15 Volts 5 287/288
Volts: Ph B-C Instantaneous Voltage Phase B to Phase C AI16 Volts 5 289/290
Volts: Ph A-C Instantaneous Voltage Phase A to Phase C AI17 Volts 5 291/292
Volts: Ph A-N Instantaneous Voltage Phase A to Neutral AI18 Volts 5 293/294
Volts: Ph B-N Instantaneous Voltage Phase B to Neutral AI19 Volts 5 295/296
Volts: Ph C-N Instantaneous Voltage Phase C to Neutral AI20 Volts 5 297/298
Amps: Ph A Instantaneous Current Phase A AI21 Amps 5 299/300
Amps: Ph B Instantaneous Current Phase B AI22 Amps 5 301/302
Amps: Ph C Instantaneous Current Phase C AI23 Amps 5 303/304
Alarm Error Bitmap Alarm Error Bitmap AI24 n/a 0 146
Count of Energy
Accumulator Resets
Count of Energy Accumulator Resets AI25 n/a 0 147
Analog_Value objects: (can be written as well as read)
Reset: write values to
reset configs
30078= Clear All Accumulators AV1 n/a 0 129 Reset:
- Write 30078 to clear all energy accumulators to 0 (All).
- Read always returns 0
System Type 10, 11, 12, 30, 31, 32, 40, 42, 44 AV2 n/a 0 130
CT Ratio Primary CT Ratio Primary (1A to 32767A) AV3 n/a 0 131
CT Ratio Secondary CT Ratio Secondary (1=1AC 5=5A) AV4 n/a 0 132 Not used on H84xx-V models (reads 32768)
PT Ratio Primary Potential Transformer Ratio Primary AV5 n/a 0 133
PT Ratio Scale (0 =
No PT)
0, 1, 10, 100 (0 = no PT) AV6 n/a 0 134
PT Ratio Secondary 100, 110, 115, 120 AV7 n/a 0 135
Service Frequency 50 or 60 Hz AV8 Hz 0 136
Display Units Display Units (0=IEC 1=IEEE) AV9 n/a 0 137
