E8950 INSTALLATION GUIDE
ZL0105-0B PAGE 16 ©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected] 02131
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Data Variable Description BACnet
Object
Units COV_
Increment
Modbus
Address
Comments
kW: Total Export Max.
Demand
Total Export Real Power Max. Demand AI25 kW 0 305/306 This retains the largest negative (Export) value measured
for Total Real Power Demand (AI19) for any single demand
interval since the Max Demand were last explicitly reset
via AV1 (this is also reset when the demand interval is
changed).
kVAR: Total Export Max.
Demand
Total Export Reactive Power Max.
Demand
AI26 kVAR 0 307/308 This retains the largest negative (Export) value measured for
Total Reactive Power Demand (AI20) for any single demand
interval since the Max Demand were last explicitly reset
via AV1 (this is also reset when the demand interval is
changed).
kVA: Total Export Max.
Demand
Total Export Apparent Power Max.
Demand
AI27 kVA 0 309/310 This retains the largest negative (Export) value measured
for Total Apparent Power Demand (AI21) for any single
demand interval since the Max Demand were last explicitly
reset via AV1 (this is also reset when the demand interval is
changed).
Reserved_AI28 (Reserved_AI28) AI28 kVA 1 311/312 This retains the largest negative (Export) value measured
for Total Apparent Power Demand (AI21) for any single
demand interval since the Max Demand were last explicitly
reset via AV1 (this is also reset when the demand interval is
changed).
Pulse Counter 1 Import
Real Energy
Pulse Counter 1 Import Real Energy AI29 n/a 0 313/314 Contact closure counter for Real Energy Import pulse output.
Check Pulse setup on the LCD display for the weight of each
pulse output count. These values are derived from 32 bit
integer counter and roll over to 0 when the integer counters
do.
Write 16498 (0x4072) to the Present_Value property of
Analog_Value object AV1 to reset both Pulse Counters to 0.
Pulse Counter 2 Export
Real Energy
Pulse Counter 2 Export Real Energy AI30 n/a 0 315/316 Contact closure counter for Real Energy Export pulse output
(there is no physical output for this, but the pulses are
counted anyway). Check Pulse setup on the LCD display
for the weight of each pulse output count. These values
are derived from 32 bit integer counter and roll over to 0
when the integer counters do. Write 16498 (0x4072) to the
Present_Value property of Analog_Value object AV1 to reset
both Pulse Counters to 0.
kWh Energy: Import
Ph A
Accumulated Real Energy Import Ph A AI31 kWh 0 317/318
kWh Energy: Import
Ph B
Accumulated Real Energy Import Ph B AI32 kWh 0 319/320
kWh Energy: Import
Ph C
Accumulated Real Energy Import Ph C AI33 kWh 0 321/322
kWh Energy: Export
Ph A
Accumulated Real Energy Export Ph A AI34 kWh 0 323/324
kWh Energy: Export
Ph B
Accumulated Real Energy Export Ph B AI35 kWh 0 325/326
kWh Energy: Export
Ph C
Accumulated Real Energy Export Ph C AI36 kWh 0 327/328
kVARh: Q1 Ph A Accumulated Q1 Reactive Energy Ph A AI37 kWh 0 329/330
kVARh: Q1 Ph B Accumulated Q1 Reactive Energy Ph B AI38 kWh 0 331/332
kVARh: Q1 Ph C Accumulated Q1 Reactive Energy Ph C AI39 kWh 0 333/334
kVARh: Q2 Ph A Accumulated Q2 Reactive Energy Ph A AI40 kWh 0 335/336
kVARh: Q2 Ph B Accumulated Q2 Reactive Energy Ph B AI41 kWh 0 337/338
kVARh: Q2 Ph C Accumulated Q2 Reactive Energy Ph C AI42 kWh 0 339/340
kVARh: Q3 Ph A Accumulated Q3 Reactive Energy Ph A AI43 kWh 0 341/342
kVARh: Q3 Ph B Accumulated Q3 Reactive Energy Ph B AI44 kWh 0 343/344
kVARh: Q3 Ph C Accumulated Q3 Reactive Energy Ph C AI45 kWh 0 345/346
E51C2 and E51C3 Bi-Directional Energy Meter, cont.
