Data Variable Description BACnet
Object
Units COV_
Increment
Modbus
Address
Comments
kVARh: Q4 Ph A Accumulated Q4 Reactive Energy Ph A AI46 kWh 0 347/348
kVARh: Q4 Ph B Accumulated Q4 Reactive Energy Ph B AI47 kWh 0 349/350
kVARh: Q4 Ph C Accumulated Q4 Reactive Energy Ph C AI48 kWh 0 351/352
kVAh: Import Ph A Accumulated Appar. Energy Import Ph A AI49 kWh 0 353/354
kVAh: Import Ph B Accumulated Appar. Energy Import Ph B AI50 kWh 0 355/356
kVAh: Import Ph C Accumulated Appar. Energy Import Ph C AI51 kWh 0 357/358
kVAh: Export Ph A Accumulated Appar. Energy Export Ph A AI52 kWh 0 359/360
kVAh: Export Ph B Accumulated Appar. Energy Export Ph B AI53 kWh 0 361/362
kVAh: Export Ph C Accumulated Appar. Energy Export Ph C AI54 kWh 0 363/364
kW: Ph A Instantaneous Real Power Phase A AI55 kW 1 365/366
kW: Ph B Instantaneous Real Power Phase B AI56 kW 1 367/368
kW: Ph C Instantaneous Real Power Phase C AI57 kW 1 369/370
kVAR: Ph A Instantaneous Reactive Power Phase A AI58 kVAR 1 371/372
kVAR: Ph B Instantaneous Reactive Power Phase B AI59 kVAR 1 373/374
kVAR: Ph C Instantaneous Reactive Power Phase C AI60 kVAR 1 375/376
kVA: Ph A Instantaneous Apparent Power Phase A AI61 kVA 1 377/378
kVA: Ph B Instantaneous Apparent Power Phase B AI62 kVA 1 379/380
kVA: Ph C Instantaneous Apparent Power Phase C AI63 kVA 1 381/382
PF: Ph A Instantaneous Power Factor Phase A AI64 PF 0.01 383/384
PF: Ph B Instantaneous Power Factor Phase B AI65 PF 0.01 385/386
PF: Ph C Instantaneous Power Factor Phase C AI66 PF 0.01 387/388
Volts: Ph A-B Instantaneous Voltage Phase A to Phase B AI67 Volts 5 389/390
Volts: Ph B-C Instantaneous Voltage Phase B to Phase C AI68 Volts 5 391/392
Volts: Ph A-C Instantaneous Voltage Phase A to Phase C AI69 Volts 5 393/394
Volts: Ph A-N Instantaneous Voltage Phase A to Neutral AI70 Volts 5 395/396
Volts: Ph B-N Instantaneous Voltage Phase B to Neutral AI71 Volts 5 397/398
Volts: Ph C-N Instantaneous Voltage Phase C to Neutral AI72 Volts 5 399/400
Amps: Ph A Instantaneous Current Phase A AI73 Amps 5 401/402
Amps: Ph B Instantaneous Current Phase B AI74 Amps 5 403/404
Amps: Ph C Instantaneous Current Phase C AI75 Amps 5 405/406
Max_Power Max Power AI76 kW 0 135
Reserved_AI77 (Reserved AI77) AI77 n/a 65535 136
Energy_Resets Count of Energy_Resets AI78 n/a 0 147
Reserved_AI79 Reserved_AI79 AI79 n/a 65535 148
Reserved_AI80 Reserved_AI80 AI80 n/a 65535 151
Power_Up_Count Count of Power Up Cycles AI81 n/a 0 152
Output_Config Output Configuration AI82 n/a 0 153
Alarm Error Bitmap Bitmap of all alarm bits AI83 n/a 0 146
E51C2 and E51C3 Bi-Directional Energy Meter, cont.
