Data Variable
Description
BACnet
Object
Units
COV_
Increment
Modbus
Address
Comments
kW Present Demand:
Channel 3
Present Real Power
Demand - Channel 3
AI238
kW
1
2340/2341
kW Present Demand:
Channel 4
Present Real Power
Demand - Channel 4
AI239
kW
1
2342/2343
kW Present Demand:
Channel 5
Present Real Power
Demand - Channel 5
AI240
kW
1
2344/2345
kW Present Demand:
Channel 6
Present Real Power
Demand - Channel 6
AI241
kW
1
2346/2347
kW Present Demand:
Channel 7
Present Real Power
Demand - Channel 7
AI242
kW
1
2348/2349
kW Present Demand:
Channel 8
Present Real Power
Demand - Channel 8
AI243
kW
1
2350/2351
kW Present Demand:
Channel 9
Present Real Power
Demand - Channel 9
AI244
kW
1
2352/2353
kW Present Demand:
Channel 10
Present Real Power
Demand - Channel 10
AI245
kW
1
2354/2355
kW Present Demand:
Channel 11
Present Real Power
Demand - Channel 11
AI246
kW
1
2356/2357
kW Present Demand:
Channel 12
Present Real Power
Demand - Channel 12
AI247
kW
1
2358/2359
kW Present Demand:
Channel 13
Present Real Power
Demand - Channel 13
AI248
kW
1
2360/2361
kW Present Demand:
Channel 14
Present Real Power
Demand - Channel 14
AI249
kW
1
2362/2363
kW Present Demand:
Channel 15
Present Real Power
Demand - Channel 15
AI250
kW
1
2364/2365
kW Present Demand:
Channel 16
Present Real Power
Demand - Channel 16
AI251
kW
1
2366/2367
kW Present Demand:
Channel 17
Present Real Power
Demand - Channel 17
AI252
kW
1
2368/2369
kW Present Demand:
Channel 18
Present Real Power
Demand - Channel 18
AI253
kW
1
2370/2371
kW Present Demand:
Channel 19
Present Real Power
Demand - Channel 19
AI254
kW
1
2372/2373
kW Present Demand:
Channel 20
Present Real Power
Demand - Channel 20
AI255
kW
1
2374/2375
kW Present Demand:
Channel 21
Present Real Power
Demand - Channel 21
AI256
kW
1
2376/2377
kW Present Demand:
Channel 22
Present Real Power
Demand - Channel 22
AI257
kW
1
2378/2379
kW Present Demand:
Channel 23
Present Real Power
Demand - Channel 23
AI258
kW
1
2380/2381
kW Present Demand:
Channel 24
Present Real Power
Demand - Channel 24
AI259
kW
1
2382/2383
kW Present Demand:
Channel 25
Present Real Power
Demand - Channel 25
AI260
kW
1
2384/2385
kW Present Demand:
Channel 26
Present Real Power
Demand - Channel 26
AI261
kW
1
2386/2387
kW Present Demand:
Channel 27
Present Real Power
Demand - Channel 27
AI262
kW
1
2388/2389
kW Present Demand:
Channel 28
Present Real Power
Demand - Channel 28
AI263
kW
1
2390/2391
E30A042 and E30A142x Branch Circuit Power Meter, cont.
