Data Variable
Description
BACnet
Object
Units
COV_
Increment
Modbus
Address
Comments
Amps: Channel 19
Instantaneous Current -
Channel 19
AI212
Amps
5
2288/2289
Amps: Channel 20
Instantaneous Current -
Channel 20
AI213
Amps
5
2290/2291
Amps: Channel 21
Instantaneous Current -
Channel 21
AI214
Amps
5
2292/2293
Amps: Channel 22
Instantaneous Current -
Channel 22
AI215
Amps
5
2294/2295
Amps: Channel 23
Instantaneous Current -
Channel 23
AI216
Amps
5
2296/2297
Amps: Channel 24
Instantaneous Current -
Channel 24
AI217
Amps
5
2298/2299
Amps: Channel 25
Instantaneous Current -
Channel 25
AI218
Amps
5
2300/2301
Amps: Channel 26
Instantaneous Current -
Channel 26
AI219
Amps
5
2302/2303
Amps: Channel 27
Instantaneous Current -
Channel 27
AI220
Amps
5
2304/2305
Amps: Channel 28
Instantaneous Current -
Channel 28
AI221
Amps
5
2306/2307
Amps: Channel 29
Instantaneous Current -
Channel 29
AI222
Amps
5
2308/2309
Amps: Channel 30
Instantaneous Current -
Channel 30
AI223
Amps
5
2310/2311
Amps: Channel 31
Instantaneous Current -
Channel 31
AI224
Amps
5
2312/2313
Amps: Channel 32
Instantaneous Current -
Channel 32
AI225
Amps
5
2314/2315
Amps: Channel 33
Instantaneous Current -
Channel 33
AI226
Amps
5
2316/2317
Amps: Channel 34
Instantaneous Current -
Channel 34
AI227
Amps
5
2318/2319
Amps: Channel 35
Instantaneous Current -
Channel 35
AI228
Amps
5
2320/2321
Amps: Channel 36
Instantaneous Current -
Channel 36
AI229
Amps
5
2322/2323
Amps: Channel 37
Instantaneous Current -
Channel 37
AI230
Amps
5
2324/2325
Amps: Channel 38
Instantaneous Current -
Channel 38
AI231
Amps
5
2326/2327
Amps: Channel 39
Instantaneous Current -
Channel 39
AI232
Amps
5
2328/2329
Amps: Channel 40
Instantaneous Current -
Channel 40
AI233
Amps
5
2330/2331
Amps: Channel 41
Instantaneous Current -
Channel 41
AI234
Amps
5
2332/2333
Amps: Channel 42
Instantaneous Current -
Channel 42
AI235
Amps
5
2334/2335
kW Present Demand:
Channel 1
Present Real Power
Demand - Channel 1
AI236
kW
1
2336/2337
kW Present Demand:
Channel 2
Present Real Power
Demand - Channel 2
AI237
kW
1
2338/2339
E30A042 and E30A142x Branch Circuit Power Meter, cont.
