E8950 INSTALLATION GUIDE
ZL0105-0B PAGE 66 ©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected] 02131
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Data Variable Description BACnet
Object
Units COV_
Increment
Modbus
Address
Comments
Amps: Channel 23 Instantaneous Current -
Channel 23
AI90 Amps 5 2296/2297
Amps: Channel 24 Instantaneous Current -
Channel 24
AI91 Amps 5 2298/2299
Amps: Channel 25 Instantaneous Current -
Channel 25
AI92 Amps 5 2300/2301
Amps: Channel 26 Instantaneous Current -
Channel 26
AI93 Amps 5 2302/2303
Amps: Channel 27 Instantaneous Current -
Channel 27
AI94 Amps 5 2304/2305
Amps: Channel 28 Instantaneous Current -
Channel 28
AI95 Amps 5 2306/2307
Amps: Channel 29 Instantaneous Current -
Channel 29
AI96 Amps 5 2308/2309
Amps: Channel 30 Instantaneous Current -
Channel 30
AI97 Amps 5 2310/2311
Amps: Channel 31 Instantaneous Current -
Channel 31
AI98 Amps 5 2312/2313
Amps: Channel 32 Instantaneous Current -
Channel 32
AI99 Amps 5 2314/2315
Amps: Channel 33 Instantaneous Current -
Channel 33
AI100 Amps 5 2316/2317
Amps: Channel 34 Instantaneous Current -
Channel 34
AI101 Amps 5 2318/2319
Amps: Channel 35 Instantaneous Current -
Channel 35
AI102 Amps 5 2320/2321
Amps: Channel 36 Instantaneous Current -
Channel 36
AI103 Amps 5 2322/2323
Amps: Channel 37 Instantaneous Current -
Channel 37
AI104 Amps 5 2324/2325
Amps: Channel 38 Instantaneous Current -
Channel 38
AI105 Amps 5 2326/2327
Amps: Channel 39 Instantaneous Current -
Channel 39
AI106 Amps 5 2328/2329
Amps: Channel 40 Instantaneous Current -
Channel 40
AI107 Amps 5 2330/2331
Amps: Channel 41 Instantaneous Current -
Channel 41
AI108 Amps 5 2332/2333
Amps: Channel 42 Instantaneous Current -
Channel 42
AI109 Amps 5 2334/2335
Amps Present Demand:
Channel 1
Present Current Demand
- Channel 1
AI110 Amps 5 2504/2505
Amps Present Demand:
Channel 2
Present Current Demand
- Channel 2
AI111 Amps 5 2506/2507
Amps Present Demand:
Channel 3
Present Current Demand
- Channel 3
AI112 Amps 5 2508/2509
Amps Present Demand:
Channel 4
Present Current Demand
- Channel 4
AI113 Amps 5 2510/2511
Amps Present Demand:
Channel 5
Present Current Demand
- Channel 5
AI114 Amps 5 2512/2513
Amps Present Demand:
Channel 6
Present Current Demand
- Channel 6
AI115 Amps 5 2514/2515
E30Bxxx/Cxxx and E31Bxxx/Cxxx Branch Circuit Meters cont.
