E8950 INSTALLATION GUIDE
ZL0105-0B PAGE 22 ©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected] 02131
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Data Variable Description BACnet
Object
Units COV_
Increment
Modbus
Address
Comments
kVA: Max Demand Total Apparent Power Max. Demand AI40 kVA 0 337/338
kVAR: Max Demand Total Reactive Power Max. Demand AI41 kVAR 0 339/340
Usage Hours Hours: >0.1A on at least one phase AI42 Hours 0 341/342
Usage Minutes (0.0-
59.9)
Minutes: >0.1A on at least one phase AI43 Minutes 10 343/344
Total Hours Total Hours since last timer reset AI44 Hours 0 345/346 This combination timer counts the total time for which the
absolute current on at least one phase is >0.1 Amp.
Total Minutes (0.0-
59.9)
Total Minutes since last timer reset AI45 Minutes 10 347/348 This combination timer counts the total time for which the
absolute current on at least one phase is >0.1 Amp.
Percent Usage Usage Hours / Total Hours AI46 Percent 5 349/350 This timer counts the total time since the usage timer was
reset.
Volts THD: Ph A-N Instantaneous THD Voltage Ph A - Neutral AI47 Percent 5 351/352 Percent Usage = Usage Time / Total Time .
Volts THD: Ph B-N Instantaneous THD Voltage Ph B - Neutral AI48 Percent 5 353/354
Volts THD: Ph C-N Instantaneous THD Voltage Ph C - Neutral AI49 Percent 5 355/356
Volts THD: Ph A-B Instantaneous THD Voltage Ph A - Ph B AI50 Percent 5 357/358
Volts THD: Ph B-C Instantaneous THD Voltage Ph B - Ph C AI51 Percent 5 359/360
Volts THD: Ph A-C Instantaneous THD Voltage Ph A - Ph C AI52 Percent 5 361/362
Amps THD: Ph A Instantaneous THD Current Phase A AI53 Percent 5 363/364
Amps THD: Ph B Instantaneous THD Current Phase B AI54 Percent 5 365/366
Amps THD: Ph C Instantaneous THD Current Phase C AI55 Percent 5 367/368
Alarm Error Bitmap Alarm Error Bitmap AI56 n/a 0 146 Error Bitmap:
bit 0: Phase A Voltage out of range
bit 1: Phase B Voltage out of range
bit 2: Phase C Voltage out of range
bit 3: Phase A Current out of range
bit 4: Phase B Current out of range
bit 5: Phase C Current out of range
bit 6: Frequency out of range or insufficient voltage on Phase
A to determine frequency range of 45-65 Hz.
bit 7: Reserved for future use
bit 8: Phase Loss A
bit 9: Phase Loss B
bit 10: Phase Loss C
bit 11-15: Reserved for future use
Count of Energy
Accumulator Resets
Count of Energy Accumulator Resets AI57 n/a 0 147
Analog_Value objects: (can be written as well as read)
Reset: write values to
reset configs
30078=Acc 14255=MnMx 21212=Dmd
10001=Tmr
AV1 n/a 0 129 Reset:
- Write 30078 to clear all Energy Accumulators to 0 (All).
- Write 14255 to reset all Power Min/Max to Present Values
(H84xx EDS Only).
- Write 21212 to reset Peak Demand values to Present Demand
Values (H84xx EDS Only).
- Write 10001 to clear the Usage Timers to 0 (H84xx EDS Only).
- Read always returns 0
System Type 10; 11; 12; 30; 31; 32; 40; 42; 44 AV2 n/a 0 130
CT Ratio Primary CT Ratio Primary (1A to 32767A) AV3 n/a 0 131
CT Ratio Secondary CT Ratio Secondary (1=1AC 5=5A) AV4 n/a 0 132 Not used on H84xxV (reads 32768)
PT Ratio Primary Potential Transformer Ratio Primary AV5 n/a 0 133
H8437 Series Energy Meters (H8437V, H8437VB & H8437VBS), cont.
