Data Variable Description BACnet
Object
Units COV_
Increment
Modbus
Address
Comments
kVA: Channel 37 Instantaneous Apparent
Power - Chan 37
AI524 kVA 1 2912/2913
kVA: Channel 38 Instantaneous Apparent
Power - Chan 38
AI525 kVA 1 2914/2915
kVA: Channel 39 Instantaneous Apparent
Power - Chan 39
AI526 kVA 1 2916/2917
kVA: Channel 40 Instantaneous Apparent
Power - Chan 40
AI527 kVA 1 2918/2919
kVA: Channel 41 Instantaneous Apparent
Power - Chan 41
AI528 kVA 1 2920/2921
kVA: Channel 42 Instantaneous Apparent
Power - Chan 42
AI529 kVA 1 2922/2923
Analog_Value objects:
Configuration (bit 0 is
LSB):
Configuration (bit 0 is
LSB):
AV1 n/a 1 6 Bit 0: 0 = odd-even, 1 = sequential
Bit 1: 0 = odd-even, 1 = sequential
Bits 2-15: future use
Examples:
Value 0 = Odd/Even
Value 1 = Reserved for Solid-Core
Value 2 = Sequential
Value 3 = Reserved for Solid-Core
# of Sub-Intervals per
Demand Int.
Number of Sub-Intervals
per Interval
AV2 n/a 1 71 Sets the number of sub-intervals that make a single demand interval.
For block demand, set this to 1.
Sub-Interval Length in
seconds.
Sub-Interval Length in
seconds.
AV3 n/a 1 72 Sub-Interval Length in seconds. For sync-to-comms, set this to 0.
E30A042 and E30A142x Branch Circuit Power Meter, cont.
