Page 35
TM
E8950
INSTALLATION GUIDE
ZL0105-0B
PAGE 35
©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected]
02131
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Data Variable
Description
BACnet
Object
Units
COV_
Increment
Modbus
Address
Comments
kWh: Channel 39
Real Energy - Channel 39 AI106
kWh
0
2076/2077
kWh: Channel 40
Real Energy - Channel 40 AI107
kWh
0
2078/2079
kWh: Channel 41
Real Energy - Channel 41 AI108
kWh
0
2080/2081
kWh: Channel 42
Real Energy - Channel 42 AI109
kWh
0
2082/2083
kW: Channel 1
Instantaneous Real
Power - Channel 1
AI110
kW
1
2084/2085
kW: Channel 2
Instantaneous Real
Power - Channel 2
AI111
kW
1
2086/2087
kW: Channel 3
Instantaneous Real
Power - Channel 3
AI112
kW
1
2088/2089
kW: Channel 4
Instantaneous Real
Power - Channel 4
AI113
kW
1
2090/2091
kW: Channel 5
Instantaneous Real
Power - Channel 5
AI114
kW
1
2092/2093
kW: Channel 6
Instantaneous Real
Power - Channel 6
AI115
kW
1
2094/2095
kW: Channel 7
Instantaneous Real
Power - Channel 7
AI116
kW
1
2096/2097
kW: Channel 8
Instantaneous Real
Power - Channel 8
AI117
kW
1
2098/2099
kW: Channel 9
Instantaneous Real
Power - Channel 9
AI118
kW
1
2100/2101
kW: Channel 10
Instantaneous Real
Power - Channel 10
AI119
kW
1
2102/2103
kW: Channel 11
Instantaneous Real
Power - Channel 11
AI120
kW
1
2104/2105
kW: Channel 12
Instantaneous Real
Power - Channel 12
AI121
kW
1
2106/2107
kW: Channel 13
Instantaneous Real
Power - Channel 13
AI122
kW
1
2108/2109
kW: Channel 14
Instantaneous Real
Power - Channel 14
AI123
kW
1
2110/2111
kW: Channel 15
Instantaneous Real
Power - Channel 15
AI124
kW
1
2112/2113
kW: Channel 16
Instantaneous Real
Power - Channel 16
AI125
kW
1
2114/2115
kW: Channel 17
Instantaneous Real
Power - Channel 17
AI126
kW
1
2116/2117
kW: Channel 18
Instantaneous Real
Power - Channel 18
AI127
kW
1
2118/2119
kW: Channel 19
Instantaneous Real
Power - Channel 19
AI128
kW
1
2120/2121
kW: Channel 20
Instantaneous Real
Power - Channel 20
AI129
kW
1
2122/2123
kW: Channel 21
Instantaneous Real
Power - Channel 21
AI130
kW
1
2124/2125
kW: Channel 22
Instantaneous Real
Power - Channel 22
AI131
kW
1
2126/2127
kW: Channel 23
Instantaneous Real
Power - Channel 23
AI132
kW
1
2128/2129
kW: Channel 24
Instantaneous Real
Power - Channel 24
AI133
kW
1
2130/2131
E30A042 and E30A142x Branch Circuit Power Meter, cont.
