E8950 INSTALLATION GUIDE
ZL0105-0B PAGE 21 ©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected] 02131
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
H8437 Series Energy Meters (H8437V, H8437VB & H8437VBS)
The H8437 has 66 data objects and operates at 9600 or 19200 baud.
Data Variable Description BACnet
Object
Units COV_
Increment
Modbus
Address
Comments
Analog_input objects: (Read-only)
kWh Energy: Total
Accumulated Real Energy AI1 kWh 0 259/260
kW: Total Total Instantaneous Real Power AI2 kW 1 261/262
KVA: Total Total Instantaneous Apparent Power AI3 kVA 1 263/264
kVAR: Total Total Instantaneous Reactive Power AI4 kVAR 1 265/266
PF: Total Total Instantaneous Power Factor AI5 PF 0.01 267/268
Volts: L-L Avg Voltage L-L average of active phases AI6 Volts 5 269/270
Volts: L-N Avg Voltage L-N average of active phases AI7 Volts 5 271/272
Amps: Avg Current Avg of active phases AI8 Amps 5 273/274
kW: Ph A Instantaneous Real Power Phase A AI9 kW 1 275/276
kW: Ph B Instantaneous Real Power Phase B AI10 kW 1 277/278
kW: Ph C Instantaneous Real Power Phase C AI11 kW 1 279/280
PF: Ph A Instantaneous Power Factor Phase A AI12 PF 0.01 281/282
PF: Ph B Instantaneous Power Factor Phase B AI13 PF 0.01 283/284
PF: Ph C Instantaneous Power Factor Phase C AI14 PF 0.01 285/286
Volts: Ph A-B Instantaneous Voltage Phase A to Phase B AI15 Volts 5 287/288
Volts: Ph B-C Instantaneous Voltage Phase B to Phase C AI16 Volts 5 289/290
Volts: Ph A-C Instantaneous Voltage Phase A to Phase C AI17 Volts 5 291/292
Volts: Ph A-N Instantaneous Voltage Phase A to Neutral AI18 Volts 5 293/294
Volts: Ph B-N Instantaneous Voltage Phase B to Neutral AI19 Volts 5 295/296
Volts: Ph C-N Instantaneous Voltage Phase C to Neutral AI20 Volts 5 297/298
Amps: Ph A Instantaneous Current Phase A AI21 Amps 5 299/300
Amps: Ph B Instantaneous Current Phase B AI22 Amps 5 301/302
Amps: Ph C Instantaneous Current Phase C AI23 Amps 5 303/304
Amps: Neutral Instantaneous Neutral Current AI24 Amps 0.1 305/306
Frequency Instantaneous Frequency AI25 Hz 0.01 307/308
kW: Total Min Total Real Power Minimum Value AI26 kW 0 309/310
kW: Total Max Total Real Power Maximum Value AI27 kW 0 311/312
kVAh: Total Accumulated Apparent Energy
Consumption
AI28 n/a 0 313/314
kVARh: Total Accumulated Reactive Energy
Consumption
AI29 n/a 0 315/316
kVA: Ph A Instantaneous Apparent Power Phase A AI30 kVA 1 317/318
kVA: Ph B Instantaneous Apparent Power Phase B AI31 kVA 1 319/320
kVA: Ph C Instantaneous Apparent Power Phase C AI32 kVA 1 321/322
kVAR: Ph A Instantaneous Reactive Power Phase A AI33 kVAR 1 323/324
kVAR: Ph B Instantaneous Reactive Power Phase B AI34 kVAR 1 325/326
kVAR: Ph C Instantaneous Reactive Power Phase C AI35 kVAR 1 327/328
kW: Demand Total Real Power Present Demand AI36 kW 0 329/330
kVA: Demand Total Apparent Power Present Demand AI37 kVA 0 331/332
kVAR: Demand Total Reactive Power Present Demand AI38 kVAR 0 333/334
kW: Max Demand Total Real Power Max. Demand AI39 kW 0 335/336
