TM
E8950
INSTALLATION GUIDE
ZL0105-0B
PAGE 36
©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected]
02131
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Data Variable
Description
BACnet
Object
Units
COV_
Increment
Modbus
Address
Comments
kW: Channel 25
Instantaneous Real
Power - Channel 25
AI134
kW
1
2132/2133
kW: Channel 26
Instantaneous Real
Power - Channel 26
AI135
kW
1
2134/2135
kW: Channel 27
Instantaneous Real
Power - Channel 27
AI136
kW
1
2136/2137
kW: Channel 28
Instantaneous Real
Power - Channel 28
AI137
kW
1
2138/2139
kW: Channel 29
Instantaneous Real
Power - Channel 29
AI138
kW
1
2140/2141
kW: Channel 30
Instantaneous Real
Power - Channel 30
AI139
kW
1
2142/2143
kW: Channel 31
Instantaneous Real
Power - Channel 31
AI140
kW
1
2144/2145
kW: Channel 32
Instantaneous Real
Power - Channel 32
AI141
kW
1
2146/2147
kW: Channel 33
Instantaneous Real
Power - Channel 33
AI142
kW
1
2148/2149
kW: Channel 34
Instantaneous Real
Power - Channel 34
AI143
kW
1
2150/2151
kW: Channel 35
Instantaneous Real
Power - Channel 35
AI144
kW
1
2152/2153
kW: Channel 36
Instantaneous Real
Power - Channel 36
AI145
kW
1
2154/2155
kW: Channel 37
Instantaneous Real
Power - Channel 37
AI146
kW
1
2156/2157
kW: Channel 38
Instantaneous Real
Power - Channel 38
AI147
kW
1
2158/2159
kW: Channel 39
Instantaneous Real
Power - Channel 39
AI148
kW
1
2160/2161
kW: Channel 40
Instantaneous Real
Power - Channel 40
AI149
kW
1
2162/2163
kW: Channel 41
Instantaneous Real
Power - Channel 41
AI150
kW
1
2164/2165
kW: Channel 42
Instantaneous Real
Power - Channel 42
AI151
kW
1
2166/2167
Power Factor: Channel 1
Instantaneous Power
Factor - Channel 1
AI152
PF
0.01
2168/2169
Power Factor: Channel 2
Instantaneous Power
Factor - Channel 2
AI153
PF
0.01
2170/2171
Power Factor: Channel 3
Instantaneous Power
Factor - Channel 3
AI154
PF
0.01
2172/2173
Power Factor: Channel 4
Instantaneous Power
Factor - Channel 4
AI155
PF
0.01
2174/2175
Power Factor: Channel 5
Instantaneous Power
Factor - Channel 5
AI156
PF
0.01
2176/2177
Power Factor: Channel 6
Instantaneous Power
Factor - Channel 6
AI157
PF
0.01
2178/2179
Power Factor: Channel 7
Instantaneous Power
Factor - Channel 7
AI158
PF
0.01
2180/2181
Power Factor: Channel 8
Instantaneous Power
Factor - Channel 8
AI159
PF
0.01
2182/2183
E30A042 and E30A142x Branch Circuit Power Meter, cont.
