Chapter 5 Device Network Settings
Vantage CNM User’s Guide
84
PPTP
User Name
Type the user name given to you by your ISP.
Password
Type the password associated with the user name above.
Retype to confirm
Password
Type your password again to make sure that you have entered is correctly.
Nailed-up
Connection
Select this if you do not want the connection to time out.
Idle Timeout
This value specifies the time in seconds that elapses before the device
automatically disconnects from the PPTP server.
My IP Address
Type the (static) IP address assigned to you by your ISP.
My IP Subnet
Mask
Type the subnet mask assigned to you by your ISP.
Server IP Address
Type the IP address of the PPTP server.
Connection ID/
Name
Type your identification name for the PPTP server.
Authentication
Type
Use the drop-down list box to select an authentication protocol for outgoing calls.
Options are:
CHAP/PAP - Your device accepts either CHAP or PAP when requested by this
remote node.
CHAP - Your device accepts CHAP only.
PAP - Your device accepts PAP only.
WAN IP Address
Assignment
Get automatically
from ISP
Select this option If your ISP did not assign you a fixed IP address. This is the
default selection.
Use fixed IP
address
Select this option If the ISP assigned a fixed IP address.
My WAN IP
Address
Enter your WAN IP address in this field if you selected Use Fixed IP Address.
Private
This parameter determines if the device will include this route to a remote node in
its RIP broadcasts.
Select this check box to keep this route private and not included in RIP
broadcasts. Clear this check box to propagate this route to other hosts through
RIP broadcasts.
Advanced Setup
RIP Direction
RIP (Routing Information Protocol) allows a router to exchange routing
information with other routers. The RIP Direction field controls the sending and
receiving of RIP packets.
Choose Both, None, In Only or Out Only.
When set to Both or Out Only, the device will broadcast its routing table
periodically.
When set to Both or In Only, the device will incorporate RIP information that it
receives.
When set to None, the device will not send any RIP packets and will ignore any
RIP packets received.
By default, RIP Direction is set to Both.
Table 23 Device Operation > Device Configuration > Network > WAN > WAN1/2 - PPTP
(ZyNOS ZyWALL with two WAN ports) (continued)
LABEL
DESCRIPTION
