Chapter 6 Device Security Settings
Vantage CNM User’s Guide
134
The following table describes the labels in this screen.
6.3.5 VPN Rules (Manual)
Select a device, click Device Operation in the menu bar and then click Device Configuration
> Security > VPN > VPN Rules (Manual) tab to open the VPN Rules screen. This is a read-
only menu of your IPSec rules (tunnels). Edit an IPSec rule by clicking the edit icon to
configure the associated submenus.
You may want to configure a VPN rule that uses manual key management if you are having
problems with IKE key management.
Figure 62 Device Operation > Device Configuration > VPN > Manual-Key IPSec
Table 50 Device Operation > Device Configuration > Security > VPN > VPN Rules (IKE) >
Network Policy Move
LABEL DESCRIPTION
Network Policy
Information The following fields display the general network settings of this VPN policy.
Name This field displays the policy name.
Local Network This field displays one or a range of IP address(es) of the computer(s) behind
the Vantage CNM.
Remote Network This field displays one or a range of IP address(es) of the remote network
behind the remote IPsec router.
Gateway Policy
Information
Gateway Policy Select the name of a VPN rule (or gateway policy) to which you want to
associate this VPN network policy.
If you do not want to associate a network policy to any gateway policy, select
Recycle Bin from the drop-down list box. The Recycle Bin gateway policy is a
virtual placeholder for any network policy(ies) without an associated gateway
policy. When there is a network policy in Recycle Bin, the Recycle Bin
gateway policy automatically displays in the VPN Rules (IKE) screen.
Apply Click Apply to save the changes.
Cancel Click Cancel to discard all changes and return to the main VPN screen.
