ZyXEL Communications Centralized Network Management Vantage CNM - Manual (Page 62)

Chapter 5 Device Network Settings
Vantage CNM User’s Guide
62
5.2 LAN (Prestige)
"
This section refers only to the LAN screen, but the information is applicable for
the LAN, WLAN, and DMZ screens.
Use this screen to configure the DHCP settings, TCP/IP settings, and Any IP settings for the
LAN port on a device. To open this screen, click Device Operation in the menu bar, and click
Device Configuration > Network > LAN > LAN in the navigation panel.
Allow between LAN
and WAN2 Select this check box to forward NetBIOS packets from the LAN to WAN port 2
and from WAN port 2 to the LAN. If your firewall is enabled with the default policy
set to block WAN port 2 to LAN traffic, you also need to enable the default WAN
port 2 to LAN firewall rule that forwards NetBIOS traffic.
Clear this check box to block all NetBIOS packets going from the LAN to WAN
port 2 and from WAN port 2 to the LAN.
Allow between LAN
and DMZ Select this check box to forward NetBIOS packets from the LAN to the DMZ and
from the DMZ to the LAN. If your firewall is enabled with the default policy set to
block DMZ to LAN traffic, you also need to enable the default DMZ to LAN
firewall rule that forwards NetBIOS traffic.
Clear this check box to block all NetBIOS packets going from the LAN to the DMZ
and from the DMZ to the LAN.
Allow between LAN
and WLAN Select this check box to forward NetBIOS packets from the LAN to the WLAN
and from the WLAN to the LAN.
Clear this check box to block all NetBIOS packets going from the LAN to the
WLAN and from the WLAN to the LAN.
Apply Click Apply to save your changes back to the device.
Reset Click Reset to begin configuring this screen afresh.
Table 13 Device Operation > Device Configuration > LAN > LAN (continued)
LABEL DESCRIPTION
