Chapter 2 GUI Introduction
Vantage CNM User’s Guide
43
Firmware
Version
This field is only available for a ZyNOS device. Select the firmware version the device
is currently using. The pull-down menu lists only supported firmware versions. Select
Unknown if you don’t know the device’s firmware version or you cannot find your
device’s current firmware version from the list.
Note: Not all ZyXEL devices can work with Vantage CNM. See Quick
Start Guide for the supported device models and firmware
versions.
Synchronize
Type
Select Get configuration from the device if you want Vantage CNM to pull all current
device configurations into Vantage CNM. The current device configuration "overwrites"
Vantage CNM configurations.
Select Set Vantage CNM configuration to device if you want Vantage CNM to push
all current configurations from Vantage CNM to the device. The current device
configuration is then reset to the configuration settings in Vantage CNM.
Encryption
Methods
This field is only available for a ZyNOS device. The encryption options are DES and
3DES. Choose from None (no encryption), DES or 3DES. The device must be set to
the same encryption mode (and have the same encryption key) as the Vantage CNM
server.
Encryption
Key
This field is only available for a ZyNOS device. Type an eight-character alphanumeric
(“0” to “9”, “a” to “z” or "A" to "Z") for DES encryption and a 24-character alphanumeric
(“0” to “9”, “a” to “z” or "A" to "Z") for 3DES encryption.
Syslog
Server IP
Select the IP address of the device’s Vantage Report server, or, if the IP address is not
in the drop-down box, select User-Define and enter the IP address. Leave the IP
address blank if the device does not use a Vantage Report server. See
.
Device
Owner
Select the owner’s name of the device. You have to go to CNM System Setting >
Device Owner screen to add device owners first.
Device Login
Select HTTPS to use HTTPS connection when login the device’s web configurator from
Vantage CNM.
Select HTTP to use HTTP connection when login the device’s web configurator from
Vantage CNM.
Device Login
Username
This field is only available for a ZLD device. Type the administrator’s login name of the
device in this field.
Device Login
Password
This field is only available for a ZLD device. Type the administrator’s login password of
the device in this field.
Device HA
This field is only available for a ZLD device. Select this if you want to monitor the
device’s device HA status from the Vantage CNM. After you select this, the Device
Role field appears.
Device Role
Select Master or Backup for this device’s HA role.
Note: You have to select the correct role matching to the setting on the
device. Otherwise, you cannot see the related information shown
in the Monitor > Device HA status on the Vantage CNM.
Note: You have to add a master device before adding the backup
device in the same HA group.
Description
Enter a description for the ZyXEL device.
Apply
Click this to save your changes back to the OTV tree.
Reset
Click this to begin configuring this screen afresh.
Table 7 Configuration Screen: Device List (continued)
LABEL
DESCRIPTION
