Chapter 12 VPN Community
Vantage CNM User’s Guide
252
The following table describes the fields in this screen.
Table 120 VPN Management > VPN Community > Add/Edit
FIELD DESCRIPTION
VPN Community
Community Name Type a name to identify this VPN community.
Description Type a descriptive note for the VPN community.
Community Type Select a VPN community type such as Full Mesh, Hub & Spoke, or Remote
Access.
Nail Up Select this check box to turn on the nailed up feature for this VPN community.
Allow NetBIOS Traffic
Through IPSec Tunnel Select this check box to allow NetBIOS packets sent through the VPN
connection.
Enable inter-routing
between spokes This option is available if you select the Hub & Spoke community type.
Select this to allow routing among spoke devices.
Member Gateways This is avaialble if you select the Full Mesh.community type. You have to
select at least two device in this section.
Hub Gateway This is avaialble if you select the Hub & Spoke community type. You have to
select only one device in this section.
Spoke Gateways This is avaialble if you select the Hub & Spoke community type. You have to
select at least one device in this section.
Central Gateway This is avaialble if you select the Remote Access community type. You have
to select only one device in this section.
Satellite Gateways This is avaialble if you select the Remote Access community type. You have
to select at least one device in this section.
# This is the number of an individual entry.
Device Name This field displays the device name.
My IP/Domain This field identifies the WAN IP address or domain name of the member
gateway.
Note: When you select Remote Access for the community
type, make sure the central gateway’s MyIP is a fixed IP
address.
Local Network This is the network behind the member gateway. A network policy specifies
which devices (behind the IPSec routers) can use the VPN tunnel.
Add Click this to open the screen where you can select VPN gateways in this
community.
Edit Click this to edit the selected VPN gateway in this community.
Total Records This entry displays the total number of records on the current page of the list.
Phase 1
Pre-Shared Key Select Auto-generate the Vantage CNM generates a pre-shared key. Or
select User-defined and type a key from 8 to 31 case-sensitive ASCII
characters or from 16 to 62 hexadecimal ("0-9", "A-F") characters. You must
precede a hexadecimal key with a "0x (zero x), which is not counted as part of
the 16 to 62 character range for the key. For example, in
"0x0123456789ABCDEF", 0x denotes that the key is hexadecimal and
0123456789ABCDEF is the key itself.
Negotiation Mode Select Main or Aggressive from the drop-down list box.
