Chapter 10 Firmware Management
Vantage CNM User’s Guide
237
10.2 Scheduler List
Use this screen to look at and maintain the list of scheduled firmware upgrades in Vantage
CNM. Once an upgrade is completed, Vantage CNM removes the upgrade record from this
screen and adds it to the Log & Report > Operation Report > Firmware Upgrade Report.
See
Section 18.1 on page 279 . To open this screen, click a folder or a device, click Device
Operation in the menu bar and then click Firmware Management > Scheduler List.
Figure 125 Device Operation > Firmware Management > Scheduler List
The following table describes the fields in this screen.
10.3 Firmware Upgrade
Use this menu item to upload ZyXEL device firmware from Vantage CNM to one or more
devices. You have to use the Device Operation > Firmware Management > Firmware List
menu item to upload firmware files from the ZyXEL FTP site (or other source) to Vantage
CNM first. See
Section 10.1 on page 235 .
Table 111 Device Operation > Firmware Management > Scheduler List
TYPE DESCRIPTION
Page Size Select this from the list box to set up to how many records you want to see in
each page.
# This is the number of an individual entry.
FW Alias This is a descriptive name for the firmware. This is specified when the firmware
is uploaded. See
Section 10.1.1 on page 236 .
Upgrade Time This field displays the time the upgrade is scheduled to occur.
Device Type This field displays the type of device that is going to be upgraded.
Total Devices This is available when you click a folder. This field displays the number of
devices that are going to be upgraded.
Description This field displays any additional information the administrator provided when
setting up this upgrade.
Admin This field displays the administrator who scheduled this upgrade.
Add This is available if you click a folder. Click this to set up a firmware upgrade.
Vantage CNM returns to the screen in
Figure 126 on page 238 .
Edit This is available if you click a folder. Click this to modify a schedule.
Delete Click to cancel or delete the selected upgrade(s) from Vantage CNM.
