Chapter 5 Device Network Settings
Vantage CNM User’s Guide
76
PPTP
User Name
Type the user name given to you by your ISP.
Password
Type the password associated with the User Name above.
Retype to confirm
Password
Type your password again to make sure that you have entered it correctly.
Nailed-up Connection
Select Nailed-Up Connection if you do not want the connection to time out.
Idle Timeout
This value specifies the time in seconds that elapses before the device
automatically disconnects from the PPTP server.
My IP Address
Type the (static) IP address assigned to you by your ISP.
My IP Subnet Mask
The device will automatically calculate the subnet mask based on the IP
address that you assign. Unless you are implementing subnetting, use the
subnet mask computed by the device.
Server IP Address
Type the IP address of the PPTP server.
Connection ID/Name
Type your identification name for the PPTP server.
Authentication Type
Use the drop-down list box to select an authentication protocol for outgoing
calls. Options are:
CHAP/PAP - Your Vantage CNM accepts either CHAP or PAP when
requested by this remote node.
CHAP - Your Vantage CNM accepts CHAP only.
PAP - Your Vantage CNM accepts PAP only.
WAN:IP
WAN IP Address
Assignment
Select Get automatically from ISP If your ISP did not assign you a fixed IP
address. This is the default selection.
Select Use fixed IP address If the ISP assigned a fixed IP address.
My WAN IP Address
Enter your WAN IP address in this field if you selected Use Fixed IP
Address.
Private
This parameter determines if the device will include the route to this remote
node in its RIP broadcasts. If set to Yes, this route is kept private and not
included in RIP broadcast. If No, the route to this remote node will be
propagated to other hosts through RIP broadcasts.
Advanced Setup
RIP Direction
RIP (Routing Information Protocol) allows a router to exchange routing
information with other routers. The RIP Direction field controls the sending
and receiving of RIP packets.
Choose Both, None, In Only or Out Only.
When set to Both or Out Only, the device will broadcast its routing table
periodically.
When set to Both or In Only, the device will incorporate RIP information that
it receives.
When set to None, the device will not send any RIP packets and will ignore
any RIP packets received.
By default, RIP Direction is set to Both.
Table 20 Device Operation > Device Configuration > Network > WAN > ISP (PPTP) – ZyNOS
ZyWALL (one WAN port) (continued)
LABEL
DESCRIPTION
