Chapter 14 VPN Monitor
Vantage CNM User’s Guide
263
Figure 148 VPN Management > VPN Monitor > By Device > SA Monitor
The following table describes the fields in this screen.
Table 128 VPN Management > VPN Monitor > By Device > SA Monitor
LABEL DESCRIPTION
Page Size Select this from the list box to set up to how many records you want to see in
each page.
# This is the number of an individual entry.
Device Name This displays the name of the device.
Device Type This displays the model of the device.
Up Tunnels This displays how many tunnels has been established.
Last Update Time This displays when the information was last updated.
Show Detail Click this to see the detailed VPN settings of the device. See Section 14.2.1
on page 258 .
Total Records This entry displays the total number of records on the current page of the list.
