Telephone Button Programming
600 Series Programs
Strata CIX/CTX Telephone Button Programming 11/04
1-91
T
e
le
phon
e Butt
on
Pr
og
ramm
ing
600 Series Programs
Table 1-38 Programs 650~660
Button Sequence Value(s) Summary
650 Behind Centrex
Assignment
650 , Hold
Assigns parameters for operation behind Centrex or another PBX
650-00 OLG Number
n, Hold
n = 1~32 (CTX100)
1~50 (CTX670 Basic)
1~128 (CTX670 Exp.) Specify OLG Number that is attached to a Centrex or another PBX.
(1~128 Expanded; 1~47 Basic)
650-01 Behind Centrex
FB01
, n,
Hold
n = 1:Enable
2:Disable (default)
Enable or disable Behind Centrex operation for this OLG.
650-02 Assume 9
FB02
, n,
Hold
n = 1:Enable
2:Disable (default)
Check to turn on the Assume 9 feature.
650-03 Pause Timer
(Seconds)
FB03
, n,
Hold
n = 0~5
(default = 0)
Enter the number of seconds (0~5) the CTX will wait for second dial
tone from Centrex/PBX.
651 Private Routing Plan
Analysis Table
Assignment
651 , Hold
Assigns Node IDs to Route Choice Tables for Private Networking
651-00
Node ID
n, Hold .
n = Up to 6-digits. Enter the Node ID to be associated with a Private Route Choice Table
Number.
651-01 Private Network
Route Choice Table
Number
FB01 , n, Hold , Hold
n = 0~64, 0 = Delete Note Enter the Private Route Choice Table Number to be
associated with this Node ID. Entering м0о deletes the Node
ID.
653 Private Route Choice
Table Assignment
653 , Hold
Use this command to define a Private Network Route Choice Table. A
Private Network Route Choice Table contains up to six Route
Definitions. The system will step through these Route Definitions in
terminating hunt fashion to find a route to the desired Private Network
networking node. There may be up to 64 Route Choice Tables.
653-00 Private Network
Route Choice Table
Number.
n, Hold ,
n = 1~64, 0 = delete Enter the Private Network Route Choice Table Number (1~64).
653-
01~06 01 Route Definition
Table~06 Route
Definition Table
FB01
~ FB06 , n, Hold ,
Hold
n = 0~64, 0 = delete Enter the first, second, third, fourth, fifth, last Route Definition Table to
be used for for this Private Network Route Choice. Entering м0о will
delete an existing entry.
654 Private Route
Definition Table
Assignment
654 , Hold
Use this command to define a Private Network Route Definition. A
Private Network Route Definition consists of an Outgoing Line Group
(OLG) and a pointer into the Private Network Digit Modification Table
that contains the dialed digits to be deleted and/or inserted before
being communicated to the distant node.
654-00 Private Network
Route Definition
n, Hold
n = 1~64 Enter the number of the Private Network Route Definition (1~64) to be
defined or deleted.
654-01 OLG
FB01 , n, Hold
n = 1~32 (CTX100)
1~50 (CTX670 Basic)
1~128 (CTX670 Exp.)
0 = delete Enter the OLG to be used by this route definition.(1~128 Expanded;
1~47 Basic)
654-02 Digit Modification
Table
FB02 , n, Hold , Hold
n = 0~64, 0 = delete Enter the Digit Modification Table Number (1~64) to be used by this
route definition.
