Telephone Button Programming
300 Series Programs
1-56
Strata CIX/CTX Telephone Button Programming 11/04
302-28
Layer 1 Short Break
Tolerant
FB28
, n,
Hold
n =
1.
Enable
2.
Disable
Sets this span as Side A or Side B for Layer 3 of a QSIG PRI. The
opposite value must be set for the node in which this QSIG PRI
terminates. (Not used in U.S.A. Used in the UK.)
302-29
2-B channel Transfer
FB29
, n,
Hold
n =
1.
Enable
2.
Disable
Enable this option to allow 2-B channel conference on PRI calls. This
allows to PRI channels to be connected in the same conference or
Tandem call.
Note
This option must also be enabled by PRI provider to allow it to
work.
302-30
Q931 Protocol Timer
FB30
, n,
Hold
n =
1.
Normal
2.
Long
Sets the Q931 Protocol Timer. If Long is set, T303 is 8s and T301 is
300s.
Table 1-27
Bearer Services Table
Bearer Services
Nat’l ISDN
ETSI
TTC
Circuit
Mode
Speech
X
X
X
3.1 KHz Audio
X
X
X
7 KHz Audio
X
X
unrestricted digital
information
64 kbps
X
X
X
Rate adaptation from 56
kbps
X
2x64
X
X
384kbp (H0)
X
X
X
1536kbps (H11)
X
X
X
1920kbps (H12)
X
multirate (n x 64 kbps)
X
Restricted digital Information
X
X
Video
X
X
Packet
Mode
Shelf/Slot/Circuit
Table 1-28
Programs 303~315
Button
Sequence
Value(s)
Summary
303
ISDN Trunk Delete
303
,
Hold
This command deletes ISDN Trunks.
303-00
Channel Group
Number
n,
Hold
,
Hold
n =
1~32 (CTX100)
1~48 (CTX670 Basic)
1~128 (CTX670 Exp.)
Enter the channel group number to delete.
304
Incoming Line Group
Assignment
303
,
Hold
This assignment is used to configure ILGs only, OLGs are configured
in the Outgoing Line Group Assignment 306. The same line can be
placed in an ILG and OLG.
304-00
Group Number
n,
Hold
n =
1~32 (CTX100)
1~50 (CTX670 Basic)
1~128 (CTX670 Exp.)
Enter the group number of the line group that should be configured.
Table 1-26
Programs 300~302
(continued)
Button
Sequence
Value(s)
Summary
