Telephone Button Programming
300 Series Programs
Strata CIX/CTX Telephone Button Programming 11/04
1-67
T
e
le
phon
e Butt
on
Pr
og
ramm
ing
317-13
B Ch Selection
FB13
, n,
Hold
n =
1.
Forward Cyclic
2.
Backward Cyclic
(default)
3.
Forward Terminal
4.
Backward Terminal
Choose Idle B Channel selection method.
•
Select Forward Cyclic (from lowest number to highest number of
B-channel).
•
Select Backward Cyclic (from highest number to lowest number
of B-channel).
•
Select Forward Terminal for the lowest numbered B-channel.
Select Backward Terminal for the oldest number B-channel. (The
High-High B-channel selection)
317-14
Initialize Type
FB14
, n,
Hold
n =
1.
User Entry Of SPID
Auto SPID ON
2.
User Entry Of SPID
Auto SPID OFF
3.
Auto SPID
4.
None
(default)
Enter the Service Profile Identifier (SPID) type of initialization.
317-15
Initialization Display
FB15
, n,
Hold
n =
Up to 4 digits
(default = User)
Enter the text to be displayed for SPID Initialization.
317-16
SPID #1
FB16
, n,
Hold
n =
Up to 20 digits
Enter the SPID value. These fields are required if you selected
National ISDN in Protocol. When no data is entered, any previously
entered information is overwritten.
317-17
SPID #2
FB17
, n,
Hold
n =
Up to 20 digits
317-18
T-Wait Timer
FB18
, n,
Hold
n =
1.
Enable
2.
Disable
(default)
Enable the T-Wait Timer. This field is needed if you selected National
ISDN in Protocol above. This timer, used along with the SPID, assigns
random initializing SPID times to prevent BRI interfaces from re-
initialize at the same time after a reset or power outage.
317-19
Voice Calls
FB19
, n,
Hold
n =
1.
One
2.
Two
(default)
Select the number of simultaneous voice (speech) calls that can exist
at the same time on this interface.
317-20
Trunk Subscriber 1
FB20
, n,
Hold
n =
Up to 10 digits
Enter the telephone number for subscriber 1. Telephone number
should be consistent with D channel data. If no data is entered in this
field any previously programmed information is lost.
317-21
Trunk Subscriber 2
FB21
, n,
Hold
,
Hold
n =
Up to 10 digits
Enter the telephone number for subscriber number 2. If no data is
entered in this field any previously programmed information is lost.
Table 1-30
Bearer Capability Table
Bearer Services
Bellcore
National ISDN
ETSI
TTC
Circuit Mode
Speech
X
X
X
3.1 KHz
X
X
X
7 KHz
X
X
Unrestricted
Digital
Information
64 Kbps
X
X
X
Rate adaptation
from 56 Kbps
X
2x64 Kbps
X
X
Table 1-29
Programs 316~317
(continued)
Button
Sequence
Value(s)
Summary
