Telephone Button Programming
100 Series Programs
Strata CIX/CTX Telephone Button Programming 11/04
1-25
T
e
le
phon
e Butt
on
Pr
og
ramm
ing
113-09
Night Mode/Holiday
FB09
, hhmm,
Hold
,
Hold
hh =
mm =
hour (00~23)
minute (00~59)
9999 to delete
Enter the start time for Night Mode for the Holiday type of day. Enter
м9999о to omit this mode.
114
PAD Conference
Table Assignment
114
,
Hold
Assigns PAD values for combinations of analog trunks and
telephones in conference.
114-01
No. of Conference
Trunks
FB01
, n,
Hold
n =
0~6
0~8
1.
6 dB Net Gain
2.
3 dB Net Gain
3.
0 dB
4.
3 dB Net Loss
5.
6 dB Net Loss
6.
9 dB Net Loss
7.
12 dB Net Loss
8.
15 dB Net Loss
Enter the number of analog trunks in the conference.
114-02
No. of Conference
Telephones
FB02
, n1,
Hold
n1 =
0~8
Enter the number of analog telephones in the conference.
114-03
PAD Conference
Value
FB03
, n2,
Hold
,
Hold
n2 =
1.
6 dB Net Gain
2.
3 dB Net Gain
3.
0 dB
4.
3 dB Net Loss
5.
6 dB Net Loss
6.
9 dB Net Loss
7.
12 dB Net Loss
8.
15 dB Net Loss
Enter the desired PAD value for the combination of analog trunks and
telephones specified in 01 and 02 above. See
.
Table 1-10
PAD Conference Table
Number of
Trunks
Number of Analog Telephones
0
1
2
3
4
5
6
7
8
0
0
0
0
0
0
3
3
6
6
1
0
0
0
0
3
3
3
6
2
3
3
3
3
3
6
6
3
6
6
6
6
6
9
4
9
9
9
9
9
5
9
9
9
9
6
9
9
9
Table 1-11
Program 116
Button
Sequence
Value(s)
Summary
116
Data Initialize
116
,
Hold
This program is used to initialize the tables of selected programs in
the Strata CTX system.
116-01
FB01
, n,
Hold
,
Hold
See
.
n =
3 digit Program Number
(100~999)
Enter Program Number to be initialized.
Table 1-9
Programs 109~114
(continued)
Button
Sequence
Value(s)
Summary
