Telephone Button Programming
100 Series Programs
Strata CIX/CTX Telephone Button Programming 11/04
1-23
T
e
le
phon
e Butt
on
Pr
og
ramm
ing
Table 1-9
Programs 109~114
Button
Sequence
Value(s)
Summary
109
Music on Hold.
109
,
Hold
This command assigns external Music on Hold (MOH) and
Background Music (BGM) sources.
109-01
MOH/BGM #1
(BECU)
FB01
, n,
Hold
n =
1.
Enable (default)
2.
Disable
Enable this assignment if MOH source #1 is connected to the system
processor MOH RCA jack.
109-02
MOH/BGM #2
(BIOU1-J1)
FB02
, n,
Hold
n =
1.
Enable
2.
Disable (default)
Enable this assignment if MOH source #2 is connected to BIOU-1,
MOH RCA jack (J1).
109-03
MOH/BGM #3
(BIOU1-J2)
FB03
, n,
Hold
n =
1.
Enable
2.
Disable (default)
Enable this assignment if MOH source #3 is connected to BIOU-1,
MOH RCA jack (J2).
109-04
MOH/BGM #4
(BIOU1-J3)
FB04
, n,
Hold
n =
1.
Enable
2.
Disable (default)
Enable this assignment if MOH source #4 is connected to BIOU-1,
MOH RCA jack (J3).
109-05
MOH/BGM #5
(BIOU2-J1)
FB05
, n,
Hold
n =
1.
Enable
2.
Disable (default)
Enable this assignment if MOH source #5 is connected to BIOU-2,
MOH RCA jack (J1).
109-06
MOH/BGM #6
(BIOU2-J2)
FB06
, n,
Hold
n =
1.
Enable
2.
Disable (default)
Enable this assignment if MOH source #6 is connected to BIOU-2,
MOH RCA jack (J2).
109-07
MOH/BGM #7
(BIOU2-J3)
FB07
, n,
Hold
n =
1.
Enable
2.
Disable (default)
Enable this assignment if MOH source #7 is connected to BIOU-2,
MOH RCA jack (J3).
109
08~15
MOH/BGM #8
(RSTU)
FB08/-FB15
, xxyyzz,
Spkr
, n,
Hold
xx =
Cabinet 1 (CTX100),
01~02 (CTX670 Basic),
01~07 (CTX670 Exp.)
Enter the RSTU equipment number to which MOH/BGM source #8 or
#9~#15 are connected. Enter data as xxyyzz:
Example: If the MOH/BGM source should be a assigned to an RSTU
in cabinet 5, slot 2, circuit 3; enter 050203.
Note
A PDN can not be assigned to an RSTU equipment number if
it is to be a MOH circuit. If a PDN is assigned to the circuit
that will connect to a MOH/BGM source, you must first delete
it using PRG201
Cabinet numbers:
•
CTX100: Select 01 for Base and Expansion cabinet.
•
CTX670: Select 01 for Base and 02~07 respectively for each
Expansion cabinet.
Slot numbers:
•
CTX100: Select 01~04 for Base slots and 05~08 for Expansion
slots.
•
CTX670: Select 01~08 for Base slots and 01~10 for Expansion
slots.
yy =
Slot 01~8 (CTX100),
01~10 (CTX670
zz =
Circuit 01~08
110
Password
Assignment.
110
,
Hold
The system has two passwords levels. Logging into the system with
the Level 1 password allows you to administer all system programs
while the level 2 password provides restricted program administration.
110-00
Password Level
n,
Hold
n =
1.
Unrestricted Admin
2.
Restricted Admin
Enter the digit 1 or 2 for the password level. Enter 1 to set the
unrestricted administration password. Enter 2 to set the restricted
administration password.
Note
Level 2 users can administer all programs, but are restricted
from initializing the CTX and from updating the CTX software.
110-01
Password
FB01
, n1,
Hold
,
Hold
n1 =
Up to 16 digits
Enter a 1~16 digit password for the selected level. Each level can
have only one password.
