Telephone Button Programming
500 Series Programs
Strata CIX/CTX Telephone Button Programming 11/04
1-79
T
e
le
phon
e Butt
on
Pr
og
ramm
ing
509-04 Override QPL
FB04 , n, Hold , Hold
n = 1~16
(default =1) Select the override QPL value.
510 COS Override
Assignment
509 , Hold
Assigns Class of Service Overrides and their parameters (COS, FRL,
DRL, QPL).
510-00 COS Override Index
n, Hold
n = 1~16 Select the COS Override index.
510-01 COS Override Code
FB01 , n, Hold
n = Up to 8 digits Select the COS Override Code as entered by users. If no data is
entered in this field, any previously entered data is erased.
510-02 Set COS
FB02 , n, Hold
n = 1~32
(default = 1) Select COS number for this override code.
510-03 Set DRL
FB03 , n, Hold
n = 1~16
(default = 1) Select DRL number for this override code.
510-04 Set FRL
FB04 , n, Hold
n = 1~16
(default = 1) Select FRL number for this override code.
510-05 Set QPL
FB05 , n, Hold
n = 1~16
(default = 1) Select QPL number for this override code.
510-06 Set Network COS
FB06 , n, Hold , Hold
n = 1~32
(default = 1) Apply this override code to Network COS index
512 SMDR for System
Assignment
512 , Hold
Assigns system-wide SMDR parameters.
512-01 Caller ID Field
FB01 , n, Hold
n = 1. Enable (default)
2. Disable
Include Caller ID records in SMDR.
512-02 B Record for
Abandoned Call
FB02 , n, Hold
n = 1. Enable
2. Disable (default)
Generate B Record for an abandoned call.
512-03 ANI
FB03 , n, Hold
n = 1. Enable (default)
2. Disable
Include ANI in SMDR record.
512-04 Authorization Code
FB04 , n, Hold
n = 1. Enable
2. Disable (default)
Include authorization codes in SMDR records.
512-05 End-of-Record CR
FB05 , n, Hold , Hold
n = 1. Enable (default)
2. Disable
Include a Carriage Return (CR) at the end of an SMDR record.
513 SMDR for ILG
Assignment
513 , Hold
This program assigns SMDR parameters for ILGs.
513-00 ILG
n, Hold
n = 1~32 (CTX100)
1~50 (CTX670 Basic)
1~128 (CTX670 Exp.) Specify the ILG for which to set SMDR parameters.
513-01 Generate SMDR
Records
FB01 , n, Hold
n = 1. Enable (default)
2. Disable
Enable to generate records for this ILG
513-02 DNIS Field Indication
FB02 , n, Hold
n = 1. Enable (default)
2. Disable
Check to include DNIS information in records for this ILG.
513-03 B Record for Incoming
Call
FB03 , n, Hold
n = 1. Enable
2. Disable (default)
Enable B Record generation for incoming calls with or without
incoming SMDR being enabled.
Table 1-35 Programs 500~577 (continued)
Button Sequence Value(s) Summary
