Telephone Button Programming
900 Series Programs
Strata CIX/CTX Telephone Button Programming 11/04
1-103
T
e
le
phon
e Butt
on
Pr
og
ramm
ing
All ISDN Trunk Trace
Program start/stop of packaged detailed collection of event trace functions. This program is only available
in the telephone button programming mode.
Program Number(s): 905
Prerequisite Program:
,
and
Reference:
Install SmartMedia card
Access Sequence:
Login to programming mode from your telephone button pad:
Hold ✱#✱#1✱2✱3✱.
At the
PASSWORD=
prompt, Enter your password and press
Hold.
At the
PROG=
prompt enter
905 and press Hold.
1. Press
FB01
.
2. Select
1
, or
2
to turn on or off.
3. Press
Hold
twice to execute.
4. Press
# # Hold
to return to the
PROG
=
prompt.
5. Enter another program number to continue programming or press
# # Hold
again to exit programming
mode.
Event Trace Side Change
This program enables you to manage your ISDN protocol trace. This program is only available in the
telephone button programming mode.
Program Number(s): 906
Prerequisite Program:
Reference:
Install SmartMedia card
Access Sequence:
Login to programming mode from your telephone button pad:
Hold ✱#✱#1✱2✱3✱.
At the
PASSWORD=
prompt, Enter your password and press
Hold.
At the
PROG=
prompt enter
906 and press Hold.
1. Press
FB01
.
2. Select
1
,
2
, or
3
to select parameter.
3. Press
Hold
to execute.
4. Press
# # Hold
to return to the
PROG
=
prompt.
5. Enter another program number to continue programming or press
# # Hold
again to exit programming
mode.
Note
When the CTX 670 stops logging data, it automatically sends data to the SmartMedia card. Run the
Unmount command (Program 908) before removing the SmartMedia card to ensure complete data
transfer.
FB Name
FB
Summary
Value
LCD Prompt
Trace All ISDN
Trunks
01
Output All ISDN Trunk Events to
SmartMedia.
1:On (default)
2:Off
1:ON
2:OFF
FB Name
FB
Summary
Value
LCD Prompt
Side Change
01
Enter desired parameter number.
1:Message
2:ISDN
3:Message+ISDN
1:MESSAGE
2:ISDN
3:MESSAGE+ISDN
