Telephone Button Programming
300 Series Programs
1-54
Strata CIX/CTX Telephone Button Programming 11/04
300-11 DTMF Back Tone
FB11 , n, Hold
n = 1. Padded
2. DTMF Tone (default)
3. No Tone
Select DTMF Back Tone type.
300-12 Hunt Order
FB12 , n, Hold
n = 1~999
(default = 1)
Change the trunk hunting order sequence for this Trunk.
300-13 Immediate Cut-
Through
FB13 , n, Hold , Hold
n = 1. Enable
2. Disable (default)
This option should be enabled on a line only if the talk-path must be
established immediately after seizing a selected outgoing line.
Example, a line connected to a Central Office Ringdown circuit.
CAUTION! This option will bypass Destination Restriction
and E911 digit analysis. Do not enable this
option on a line where these functions are
required.
This option is available only on ground and loop, analog or T1 circuits.
It should not be enabled for Tie, DID, ISDN and QSIG lines.
Available with CTX R1.01, M22 and above software.
301 Delete Trunk
302 , Hold
Deletes trunks from the system.
301-01 Trunk Number
n, Hold
n = 1-264 Enter the Trunk Number to be deleted (1~264)
302 PRI Trunks
302 , Hold
The PRI and IP QSIG interface cards need to have a number of
assignments for defining its operation. These include which channels
are available for use and the location of the D channel or signaling
channel. A number of optional functional capabilities also need to be
enabled or disabled.
302-00 Channel Group
n, Hold
n = 1~32 (CTX100)
1~48 (CTX670 Basic)
1~128 (CTX670 Exp.) Channel Group Number
302-01 RPTU Equipment No.
FB01 , xxyyzz, Hold
xx = Cabinet 1 (CTX100),
01~02 (CTX670 Basic),
01~07 (CTX670 Exp.) Enter the ISDN RPTU equipment number as xxyyzz.
Note zz = Channel 01 is always used to assign RPTU parameters
Example: If the RPTU is installed in cabinet shelf 5, slot 3, enter
050301.Enter the equipment number xxyyzz to which the ISDN PRI
Trunk is to be assigned.
Equipment numbers are required when assigning ISDN RPTU
parameters in the system. It can also be used to display the
equipment location of existing RPTU PCBs.
yy = Slot 01~8 (CTX100),
01~10 (CTX670)
zz = Circuit 01
302-02 Protocol
FB02 , n, Hold
n = 1. Natíl ISDN
2. ETSI
3. TTC
4. Natíl ISDN - Nortel
5. QSIG
The Protocol to be followed defines the type of interface expected
based upon the equipment type at the distant end of the connection.
302-03 ILG
FB03 , n, Hold
n = 0~32 (CTX100)
0~48 (CTX670 Basic)
0~128 (CTX670 Exp.)
(default = 0)
Primary ISDN needs to have Trunk Group assignments to process the
calls being received. If multiple trunk groups are used within the
Channel Group, then Call-by-Call Services must be used.
302-04 OLG
FB04 , n, Hold
n = 0~32 (CTX100)
0~48 (CTX670 Basic)
0~128 (CTX670 Exp.)
(default = 0)
Primary ISDN needs to have Trunk Group assignments to process the
calls being originated. If multiple trunk groups are used within the
Channel Group, then Call-by-Call Services must be used.
302-05 Trunk ID Type
FB05 , n, Hold
n = 1. Implicit
2. Explicit
Identify whether the communication with the PSTN requires an
identifier. Select Explicit to require an identifier.
Table 1-26 Programs 300~302 (continued)
Button Sequence Value(s) Summary
