Telephone Button Programming
300 Series Programs
Strata CIX/CTX Telephone Button Programming 11/04
1-65
T
e
le
phon
e Butt
on
Pr
og
ramm
ing
315-04
Receive PAD
FB05
, n,
Hold
,
Hold
n =
1.
None
2.
Plus 6 dB
3.
Plus 3 dB
4.
Zero dB (default)
5.
Minus 3 dB
6.
Minus 6 dB
7.
Minus 9 dB
8.
Minus 12 dB
9.
Minus 15 dB
Select the Receive PAD values.
315-05
Send Pad
FB04
, n,
Hold
n =
1.
None
2.
Plus 6 dB
3.
Plus 3 dB
4.
Zero dB (default)
5.
Minus 3 dB
6.
Minus 6 dB
7.
Minus 9 dB
8.
Minus 12 dB
9.
Minus 15 dB
Select the Send PAD values.
Table 1-29
Programs 316~317
Button
Sequence
Value(s)
Summary
316
Shared D Channel
316
,
Hold
The PRI Interface can be extended to include an additional PRI card
to expand the total number of channels to 47 on a Channel Group.
This second PRI may optionally offer a backup D channel.
316-00
Channel Group
n,
Hold
n =
1~32 (CTX100)
1~48 (CTX670 Basic)
1~128 (CTX670 Exp.)
Channel Group Number.
316-01
Equipment Number
FB01
, xxyyzz,
Hold
xx =
yy =
zz =
xx = Cabinet 01, yy = 03,
05, or 07 and zz = Channel
01 is always used to assign
RPTU parameters
Enter the ISDN RPTU equipment number as xxyyzz:
Example: If the RPTU is installed in cabinet shelf 5, slot 3, enter
050301.
Cabinet numbers:
CTX100: Select 01 for Base and Expansion cabinet.
CTX670: Select 01 for Base and 02~07 respectively for each
Expansion cabinet.
Slot numbers:
CTX100: Select 01~04 for Base slots and 05~08 for Expansion slots.
CTX670: Select 01~08 for Base slots and 01~10 for Expansion slots..
or
xx = Cabinet 02~10,
yy = 01, 03, or 05 and
zz = Channel 01 is always
used to assign RPTU
parameters
316-02
Trunk ID
FB02
, n,
Hold
n =
0~126
(default = 1)
An identifier must be used as part of the addressing to communicate
with the PSTN which channel on which link is used the given call. This
identifier is assigned by the connected PSTN.
316-03
D Channel Provided
FB03
, n,
Hold
n =
1.
D-Channel
2.
No D-Channel (default)
If a backup ëDí Channel is to be used, it needs to be enabled.
316-04
Backup D Channel
Position
FB04
, n,
Hold
,
Hold
n =
1~128
(default = 24)
Channel Group Number.
317
ISDN BRI Trunk
317
,
Hold
The following program enables set up for ISDN related system
settings.
317-00
Channel Group
n,
Hold
n =
1~32 (CTX100)
1~48 (CTX670 Basic)
1~128 (CTX670 Exp.)
Enter the BRI channel Group Number.
Table 1-28
Programs 303~315
(continued)
Button
Sequence
Value(s)
Summary
