Functional Unit Constraints
4-55
Pipeline
SPRU733
Table 4−39 shows the instruction constraints for LDDW instructions executing
on the .D unit.
Table 4−39. LDDW Instruction With Long Write Instruction Constraints
Instruction Execution
Cycle
1
2
3
4
5
6
LDDW
RW
W
Instruction Type
Subsequent Same-Unit Instruction Executable
Instruction with long result
n
n
n
Xw
n
Legend:
= E1 phase of the single-cycle instruction; R = Sources read for the instruction; W = Destinations written for the
instruction;
n
= Next instruction can enter E1 during cycle; Xw = Next instruction cannot enter E1 during cycle-write
constraint
