CMPLTU

Compare for Less Than, Unsigned Integers

3-102

Instruction Set

SPRU733

Compare for Less Than, Unsigned Integers

CMPLTU

Syntax

CMPLTU (.unit) src1, src2, dst

.unit = .L1 or .L2

Compatibility

C62x, C64x, C67x, and C67x+ CPU

Opcode

31

29

28

27

23

22

18

17

13

12

11

5

4

3

2

1

0

creg

z

dst

src2

src1

x

op

1 1 0 s p

3

1

5

5

5

1

7

1

1

Opcode map field used...

For operand type...

Unit

Opfield

src1
src2
dst

uint
xuint
uint

.L1, .L2

101 1111

src1
src2
dst

ucst4
xuint
uint

.L1, .L2

101 1110

src1
src2
dst

xuint
ulong
uint

.L1, .L2

101 1101

src1
src2
dst

ucst4
ulong
uint

.L1, .L2

101 1100

Description

Performs an unsigned comparison of src1 to src2. If src1 is less than src2, then
1 is written to dst; otherwise, 0 is written to dst.

Execution

if (cond)

{
if (src1

<

src2) 1

dst

else 0

dst

}

else nop
