4. Configuration Options
9128-A2-GB20-80 September 2002 4-27
Code Point Definitions
Select Class of Service Definitions from the System menu, then PgDn or PgUp, to
display or change the Code Point definitions for a Class of Service ID. See
Configuring Class of Service Definitions on page 4-25 for instructions.
Table 4-3. Code Point Definitions
Code Pnt
Possible Settings: 000000–111111
Default Setting: None.
This read-only field shows the possible Code Points. Code Points are described in
RFC 2474.
ID
Possible Settings: 1–7
Default Setting: 1
This read-only field shows the ID associated with the Name field. If you change a name in
a Name field on this screen and select Save, the ID changes to match the name.
Name
Possible Settings: ASCII Text
Default Setting: Default
The Name field specifies the Class of Service to which you want to assign the Code Point.
ASCII Text – Specifies one of the Class of Service Names entered on the Class of
Service Definitions screen.
