4. Configuration Options

4-26

September

2002

9128-A2-GB20-80

8. Select Save, then select PgDn or PgUp. The Class of Service Definitions page

reappears. In the Code Points Assigned column next to your selected name
there is now a Y for Yes.

9. If latency and availability should be measured for the selected name, change

the N in the Measure Latency & Availability column to Y.

10. Select Save.

To configure these options, Service Type on the Easy Install screen must be set to
Frame Relay.

Table 4-2.

Class of Service Definitions

Class of Svc Name

Possible Settings:

ASCII Text Entry

Default Setting:

For IDs 2–7:

blank

For ID 1:

Default

Specifies a name to identify a Class of Service definition.

ASCII Text Entry

Enter a unique name for the definition (maximum length 8 characters).

Measure Latency & Availability

Possible Settings: N, Y
Default Setting:

For IDs 2–7:

N

For ID 1:

Y

Determines whether latency and availability are measured for this Class of Service ID.

Display Conditions

– This option is set to N and is read-only until the class of service is

defined and code points are assigned to it.

N – Latency and availability are not measured for this Class of Service ID.

Y – Latency and availability are measured for this Class of Service ID.

Code Points Assigned

Possible Settings: Y, N
Default Setting:

For IDs 2–7:

N

For ID 1:

Y

This read-only field shows whether a Code Point has been assigned to this Class of
Service ID on the Code Point Definitions screen.

N – No Code Point is assigned to this ID.

Y – At least one Code Point is assigned to this ID.
